MCP4642T-103E/UN
ActiveMicrochip Technology
DIGITAL POTENTIOMETER, NON-VOLATILE, 10 KOHM, DUAL, 129 STEPS, ± 150 PPM/°C, 2.7 V TO 5.5 V, 10 PINS… MORE
Deep-Dive with AI
Search across all available documentation for this part.
MCP4642T-103E/UN
ActiveMicrochip Technology
DIGITAL POTENTIOMETER, NON-VOLATILE, 10 KOHM, DUAL, 129 STEPS, ± 150 PPM/°C, 2.7 V TO 5.5 V, 10 PINS… MORE
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MCP4642T-103E/UN | mcp4642 Series |
|---|---|---|
| - | - | |
| Configuration | Rheostat | Rheostat |
| Features | Selectable Address | Selectable Address |
| Interface | I2C | I2C |
| Memory Type | Non-Volatile | Non-Volatile |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Circuits | 2 | 2 |
| Number of Taps | 129 | 129 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 10-MSOP, 10-TFSOP | 10-MSOP, 10-TFSOP, 10-VFDFN Exposed Pad |
| Package / Case [x] | 3 mm | 3 mm |
| Package / Case [x] | 0.118 in | 0.118 in |
| Resistance - Wiper (Ohms) (Typ) | 75 Ohms | 75 Ohms |
| Resistance (Ohms) | 10k | 10k |
| Resistance (Ohms) | - | 5 - 100 kOhms |
| Supplier Device Package | 10-MSOP | 10-MSOP, 10-DFN (3x3) |
| Taper | Linear | Linear |
| Temperature Coefficient (Typ) | 150 ppm/°C | 150 ppm/°C |
| Tolerance | 20 % | 20 % |
| Voltage - Supply [Max] | 5.5 V | 5.5 V |
| Voltage - Supply [Min] | 1.8 V | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.40 | |
| 25 | $ 1.16 | |||
| 100 | $ 1.06 | |||
| Digi-Reel® | 1 | $ 1.40 | ||
| 25 | $ 1.16 | |||
| 100 | $ 1.06 | |||
| Tape & Reel (TR) | 2500 | $ 1.06 | ||
| Microchip Direct | T/R | 1 | $ 1.40 | |
| 25 | $ 1.16 | |||
| 100 | $ 1.06 | |||
| 1000 | $ 1.02 | |||
| 5000 | $ 1.01 | |||
| Newark | Each (Supplied on Full Reel) | 100 | $ 1.10 | |
mcp4642 Series
7-Bit Dual Digital POT with NVM and I2C™
| Part | Mounting Type | Configuration | Memory Type | Resistance (Ohms) | Supplier Device Package | Features | Resistance - Wiper (Ohms) (Typ) | Number of Taps | Package / Case | Package / Case [x] | Package / Case [x] | Interface | Temperature Coefficient (Typ) | Taper | Operating Temperature [Max] | Operating Temperature [Min] | Number of Circuits | Tolerance | Voltage - Supply [Min] | Voltage - Supply [Max] | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology MCP4642-104E/UN | |||||||||||||||||||||
Microchip Technology MCP4642-503E/UN | Surface Mount | Rheostat | Non-Volatile | 50 kOhms | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | |
Microchip Technology MCP4642-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-103E/UN | Surface Mount | Rheostat | Non-Volatile | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | 10k | |
Microchip Technology MCP4642T-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642-104E/UN | Surface Mount | Rheostat | Non-Volatile | 100 kOhms | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | |
Microchip Technology MCP4642T-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642-103E/UN | Surface Mount | Rheostat | Non-Volatile | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | 10k | |
Microchip Technology MCP4642-103E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-503E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-503E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-103E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-103E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-502E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-103E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-503E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-104E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-502E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-502E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-503E/UN | Surface Mount | Rheostat | Non-Volatile | 50 kOhms | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | |
Microchip Technology MCP4642T-503E/MF | Surface Mount | Rheostat | Non-Volatile | 50 kOhms | 10-DFN (3x3) | Selectable Address | 75 Ohms | 129 | 10-VFDFN Exposed Pad | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | |||
Microchip Technology MCP4642-502E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-503E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-104E/UN | |||||||||||||||||||||
Microchip Technology MCP4642-103E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-104E/MF | Surface Mount | Rheostat | Non-Volatile | 100 kOhms | 10-DFN (3x3) | Selectable Address | 75 Ohms | 129 | 10-VFDFN Exposed Pad | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | |||
Microchip Technology MCP4642-503E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-104E/MF | |||||||||||||||||||||
Microchip Technology MCP4642T-103E/MF | Surface Mount | Rheostat | Non-Volatile | 10-DFN (3x3) | Selectable Address | 75 Ohms | 129 | 10-VFDFN Exposed Pad | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V | 10k | |||
Microchip Technology MCP4642-104E/UN | |||||||||||||||||||||
Microchip Technology MCP4642T-104E/MF | |||||||||||||||||||||
Microchip Technology MCP4642-502E/UN | Surface Mount | Rheostat | Non-Volatile | 5 kOhms | 10-MSOP | Selectable Address | 75 Ohms | 129 | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | I2C | 150 ppm/°C | Linear | 125 °C | -40 °C | 2 | 20 % | 1.8 V | 5.5 V |
Description
General part information
mcp4642 Series
The MCP464X devices are dual channel, non-volatile, 7-bit (129 wiper steps) digital potentiometers with EEPROM and an I2C compatible interface. The MCP464X family is available with end-to-end resistor values of 5KΩ, 10KΩ, 50kΩ and 100KΩ. These devices offer WiperLock™ Technology which allows the user unlimited reprogramming and locking of the wiper setting. It is useful for equipment that requires factory trimming or recalibration. The MCP464X devices offer a variety of configurations simplifying design while minimizing cost, package size and pin count.
