Description

General part information

292250 Series

PCB Mount Header, Right Angle, Wire-to-Board, 9 Position, 2 mm [.079 in] Centerline, Partially Shrouded, Tin (Sn), Through Hole - Solder, AMP CT

Technical Specifications

Parameters and characteristics for this part

Specification292250-9
ApplicationsGeneral Purpose
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Length - Mating0.165 in
Contact Length - Post0.126 in
Contact MaterialBrass
Contact ShapeSquare
Contact TypeMale Pin
Current Rating0 A
Current RatingVaries by Wire Gauge
Fastening TypeDetent Lock
Insulation ColorNatural
Insulation Height0.228 in
Insulation MaterialPolyamide (PA66), Nylon 6/6
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole, Right Angle
Number of Positions9
Number of Positions LoadedAll
Number of Rows1
Pitch - Mating0.079 in
ShroudingShrouded - 4 Wall
StyleCable/Wire, Board
TerminationKinked Pin, Solder
Voltage Rating125 V
