PET2000-12-074RD
ActiveBel Power Solutions
DC/DC CONVERTER 12V 2000W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PET2000-12-074RD
ActiveBel Power Solutions
DC/DC CONVERTER 12V 2000W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | PET2000-12-074RD | PET2000 Series |
|---|---|---|
| Applications | ITE (Commercial) | ITE (Commercial) |
| Approval Agency | CQC, EAC, NEMKO | CE, CB, CQC, EAC, NEMKO |
| Current - Output (Max) [Max] | 167 A | 167 A |
| Current - Output 1 | - | 167 A |
| Efficiency | 95 % | 92.8 - 95 % |
| Features | - | PMBus™, Standby Output, Hot Swappable, PFC, I2C Interface, Remote Sense, Load Sharing |
| Mounting Type | Rack Mount | Rack Mount |
| Number of Outputs | - | 1 |
| Operating Temperature [Max] | 40 °C | 40 °C |
| Operating Temperature [Min] | 0 °C | 0 °C |
| Power (Watts) | 2000 W | 2000 W |
| Size / Dimension [x] | 265 mm | 265 mm |
| Size / Dimension [x] | 10.43 in | 10.43 in |
| Size / Dimension [y] | 2.89 in | 2.89 in |
| Size / Dimension [y] | 73.5 mm | 73.5 mm |
| Size / Dimension [z] | 1.57 " | 1.57 " |
| Size / Dimension [z] | 40 mm | 40 mm |
| Type | Front End | Front End |
| Voltage - Input | - | 140 - 264 VAC |
| Voltage - Input | - | 90 - 180 VAC |
| Voltage - Input (Max) [Max] | 72 V | 72 V |
| Voltage - Input (Min) [Min] | 40 V | 40 V |
| Voltage - Isolation | - | 4.242 kV |
| Voltage - Output 1 | 12 V | 12 V |
PET2000 Series
AC/DC CONVERTER 12V 2000W
| Part | Features | Mounting Type | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output 1 | Number of Outputs | Power (Watts) | Efficiency | Current - Output 1 | Voltage - Isolation | Type | Applications | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Approval Agency | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Bel Power Solutions PET2000-12-074RA | Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Remote Sense, Standby Output | Rack Mount | 140 VAC, 264 VAC | 90 VAC, 180 VAC | 12 V | 1 | 2000 W | 92.8 % | 167 A | 4.242 kV | Front End | ITE (Commercial) | 2.89 in | 265 mm | 1.57 " | 40 mm | 73.5 mm | 10.43 in | CB, CE | |||||
Bel Power Solutions PET2000-12-074RD | Rack Mount | 12 V | 2000 W | 95 % | Front End | ITE (Commercial) | 2.89 in | 265 mm | 1.57 " | 40 mm | 73.5 mm | 10.43 in | CQC, EAC, NEMKO | 72 V | 40 °C | 0 °C | 167 A | 40 V | ||||||
Bel Power Solutions PET2000-12-074NA | Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Remote Sense, Standby Output | Rack Mount | 140 VAC, 264 VAC | 90 VAC, 180 VAC | 12 V | 1 | 2000 W | 92.8 % | 167 A | 4.242 kV | Front End | ITE (Commercial) | 2.89 in | 265 mm | 1.57 " | 40 mm | 73.5 mm | 10.43 in | CB, CE | |||||
Bel Power Solutions PET2000-NAS446 | Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Remote Sense, Standby Output | Rack Mount | 140 VAC, 264 VAC | 90 VAC, 180 VAC | 12 V | 1 | 2000 W | 92.8 % | 167 A | 4.242 kV | Front End | ITE (Commercial) | 2.89 in | 265 mm | 1.57 " | 40 mm | 73.5 mm | 10.43 in | CB, CE | |||||
Bel Power Solutions PET2000-12-074ND | Rack Mount | 12 V | 1 | 2000 W | 95 % | Front End | ITE (Commercial) | 2.89 in | 265 mm | 1.57 " | 40 mm | 73.5 mm | 10.43 in | CQC, EAC, NEMKO | 72 V | 167 A | 40 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 754.62 | |
| 3 | $ 709.95 | |||
| 8 | $ 681.25 | |||
Description
General part information
PET2000 Series
Front End DC DC Converter Output 12V 167A 72V Input
