3132-16-1-0500-010-1-TS
UnknownCnC Tech, LLC
HOOK-UP WIRE 16AWG 152.4M 2.45MM TINNED COPPER 300V REEL
Deep-Dive with AI
Search across all available documentation for this part.
3132-16-1-0500-010-1-TS
UnknownCnC Tech, LLC
HOOK-UP WIRE 16AWG 152.4M 2.45MM TINNED COPPER 300V REEL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 3132-16-1-0500-010-1-TS |
|---|---|
| Cable Type | Hook-Up |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 26 |
| Conductor Strand [diameter] | 0.01 in |
| Features | Oil Resistant, High Temperature |
| Jacket (Insulation) Diameter [diameter] | 0.091 " |
| Jacket (Insulation) Diameter [diameter] | 2.31 mm |
| Jacket (Insulation) Material | Fluorinated Ethylene-Propylene (FEP), Silicone Rubber |
| Jacket (Insulation) Thickness | 0.016 in, 0.015 in |
| Jacket (Insulation) Thickness | 0.41 mm, 0.38 mm |
| Jacket Color | Violet |
| Length | 15.24 m, 76.2 m |
| Length | 3000 " |
| Length [x] | 50 ft, 25 ft, 100 ft, 500 ' |
| Length [x] | 7.62 m, 30.5 m, 152.4 m |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -30 ░C |
| Ratings | UL Style 3132 |
| Voltage | 300 V |
| Wire Gauge | 16 AWG |
3132-16 Series
| Part | Conductor Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket Color | Conductor Strand [custom] | Conductor Strand [diameter] | Ratings | Length | Length [x] | Jacket (Insulation) Material | Features | Wire Gauge | Voltage | Length [x] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length | Cable Type | Operating Temperature [Max] | Operating Temperature [Min] | Spool Size | Spool Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CnC Tech, LLC | Copper Tinned | 0.015 in 0.016 in | 0.38 mm 0.41 mm | Violet | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.015 in 0.016 in | 0.38 mm 0.41 mm | Brown | 26 | 0.01 in | UL Style 3132 | 25 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | Hook-Up | 150 °C | -30 ░C | ||||
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | Black | 26 | 0.01 in | UL Style 3132 | 76.2 m | 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | Blue | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.015 in 0.016 in | 0.38 mm 0.41 mm | Green Yellow | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | 500 ' | 152.4 m |
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | Yellow | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | Green | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | Red | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C | ||
CnC Tech, LLC | Copper Tinned | 0.016 in | 0.41 mm | 26 | 0.01 in | UL Style 3132 | 15.24 m 76.2 m | 25 ft 50 ft 100 ft 500 ' | Fluorinated Ethylene-Propylene (FEP) Silicone Rubber | High Temperature Oil Resistant | 16 AWG | 300 V | 7.62 m 30.5 m 152.4 m | 0.091 " | 2.31 mm | 3000 " | Hook-Up | 150 °C | -30 ░C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 102.10 | |
| 1 | $ 24.93 | |||
| 1 | $ 44.79 | |||
| 1 | $ 19.08 | |||
| 2 | $ 97.43 | |||
| 2 | $ 23.78 | |||
| 2 | $ 12.61 | |||
| 3 | $ 41.91 | |||
| 4 | $ 92.76 | |||
| 4 | $ 12.01 | |||
| 5 | $ 40.00 | |||
| 5 | $ 22.25 | |||
| 8 | $ 214.73 | |||
| 10 | $ 86.93 | |||
| 10 | $ 38.08 | |||
| 10 | $ 21.24 | |||
| 10 | $ 11.29 | |||
| 16 | $ 202.87 | |||
| 20 | $ 10.69 | |||
| 20 | $ 20.22 | |||
| 20 | $ 82.26 | |||
| 25 | $ 35.69 | |||
| 40 | $ 78.76 | |||
| 40 | $ 10.23 | |||
| 50 | $ 18.95 | |||
| 50 | $ 33.77 | |||
| 100 | $ 17.93 | |||
| 100 | $ 9.57 | |||
| 100 | $ 32.33 | |||
| 100 | $ 75.84 | |||
| 200 | $ 9.11 | |||
| 200 | $ 17.17 | |||
| 400 | $ 8.65 | |||
| 500 | $ 16.53 | |||
| 500 | $ 31.14 | |||
Description
General part information
3132-16 Series
16 AWG Hook-Up Wire 26/0.0100" Violet 300V 250.0' (76.2m)
