1-1825058-9

1-1825058-9

Active

TE Connectivity AMP Connectors

SWITCH SLIDE DIP SPST 0.1A 24V

1-1825058-9

1-1825058-9

Active

TE Connectivity AMP Connectors

SWITCH SLIDE DIP SPST 0.1A 24V

Description Series Pricing CAD Documents

Description

General part information

ALCOSWITCH DIP ADE Series

DIP Switch, Gold Flash Contact Plating, Black, Polyphenylene Sulfide (PPS), 8 Switch, -30 – 85 °C, Extended Actuator / Slide Actuator, ALCOSWITCH DIP

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — free Log in

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

ADE _ADP_ADF_Datasheet

ENG_CD_1825058_T2.pdf

1-1825058-9 | Datasheet

ALCOSWITCH DIP ADE Series

Part	Contact Material	Mounting Type	Pitch	Pitch Type	Number of Positions	Current Rating	Actuator Level	Operating Temperature (Min)	Operating Temperature (Max)	Circuit	Termination Style	Contact Finish	Actuator Type	Height Above Board	Washable	Voltage Rating
TE Connectivity AMP Connectors ADEN10TTU04	Beryllium Copper	Through Hole	0.1 in	Full	10	0.025 A	Raised	-40 °C	85 °C	SPST	PC Pin	Gold	Slide (Standard)	0.166 in	No	24 V
TE Connectivity AMP Connectors 1825058-7
TE Connectivity AMP Connectors 1825360-1	Copper Alloy	Through Hole	0.1 in	Full	2	100 mA	Raised	-30 °C	85 °C	SPST	PC Pin	Gold	Slide (Standard)	0.228 in	Yes	24 V
TE Connectivity AMP Connectors ADEN04TTU04	Beryllium Copper	Through Hole	0.1 in	Full	4	0.025 A	Raised	-40 °C	85 °C	SPST	PC Pin	Gold	Slide (Standard)	0.166 in	No	24 V
TE Connectivity AMP Connectors 1-1825058-9
TE Connectivity AMP Connectors 1825057-7	Copper Alloy	Through Hole	0.1 in	Full	8	100 mA	Raised	-30 °C	85 °C	SPST	PC Pin	Gold	Slide (Standard)	0.228 in	Yes	24 V
TE Connectivity AMP Connectors ADEN02TTU04	Beryllium Copper	Through Hole	0.1 in	Full	2	0.025 A	Raised	-40 °C	85 °C	SPST	PC Pin	Gold	Slide (Standard)	0.166 in	No	24 V
TE Connectivity AMP Connectors 1825058-1	Copper Alloy	Surface Mount	0.1 in	Full	2	100 mA	Raised	-30 °C	85 °C	SPST	Gull Wing	Gold	Slide (Standard)	0.217 in	Yes	24 V
TE Connectivity AMP Connectors ADEN02STU04	Beryllium Copper	Surface Mount	0.1 in	Full	2	0.025 A	Raised	-40 °C	85 °C	SPST	Gull Wing	Gold	Slide (Standard)	0.179 in	No	24 V
TE Connectivity AMP Connectors 2-1825058-5	Copper Alloy	Surface Mount	0.1 in	Full	10	100 mA	Raised	-30 °C	85 °C	SPST	Gull Wing	Gold	Slide (Standard)	0.217 in	Yes	24 V
