CMB2550-0000-000N0B0A65E

Active

Cree LED

LED COB XLAMP COOL WHT SQU 6500K

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CMB2550-0000-000N0B0A65E

Active

Cree LED

LED COB XLAMP COOL WHT SQU 6500K

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CMB2550-0000-000N0B0A65E

CCT (K)	6500 K
Color	Cool, White
Configuration	Square
CRI (Color Rendering Index)	70
Current - Max [Max]	3.6 A
Height [z]	1.75 mm
Lens Type	Flat
Light Emitting Surface (LES) [diameter]	19 mm
Lumens/Watt @ Current - Test	177 lm/W
Luminous Flux @ Current/Temperature	8438 lm
Size / Dimension [x]	23.85 mm
Size / Dimension [y]	23.85 mm
Temperature - Test	85 °C
Type	Chip On Board (COB)
Viewing Angle	115 °
Voltage - Forward (Vf) (Typ)	34 V

CMB2550 Series

Part	Type	Current - Max [Max]	Viewing Angle	Light Emitting Surface (LES) [diameter]	CRI (Color Rendering Index)	Voltage - Forward (Vf) (Typ)	Lens Type	Size / Dimension [x]	Size / Dimension [y]	Temperature - Test	Color	CCT (K)	Lumens/Watt @ Current - Test	Luminous Flux @ Current/Temperature	Configuration	Height [z]
Cree LED CMB2550-R060-000N0U0A27G	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Warm White	2700 K	129 lm/W	6148 lm	Square	1.75 mm
Cree LED CMB2550-0000-000N0U0A50G	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Cool White		137 lm/W	6531 lm	Square	1.75 mm
Cree LED CMB2550-0000-000N0B0A65E	Chip On Board (COB)	3.6 A	115 °	19 mm	70	34 V	Flat	23.85 mm	23.85 mm	85 °C	Cool White	6500 K	177 lm/W	8438 lm	Square	1.75 mm
Cree LED CMB2550-0000-000N0H0A22G	Chip On Board (COB)	3.6 A	115 °	19 mm	80	34 V	Flat	23.85 mm	23.85 mm	85 °C	Warm White	2200 K	130 lm/W		Square	1.75 mm
Cree LED CMB2550-0000-000N0U0A40H	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Neutral White	4000 K	136 lm/W	6494 lm	Square	1.75 mm
Cree LED CMB2550-0000-000N0Z0A40H	Chip On Board (COB)	3.6 A	115 °	19 mm	95	34 V	Flat	23.85 mm	23.85 mm	85 °C	Neutral White	4000 K	123 lm/W	5865 lm	Square	1.75 mm
Cree LED CMB2550-R060-00PN0U0A30H	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Warm White				Square	1.75 mm
Cree LED CMB2550-0000-000N0H0A27H	Chip On Board (COB)	3.6 A	115 °	19 mm	80	34 V	Flat	23.85 mm	23.85 mm	85 °C	Warm White	2700 K	148 lm/W	7053 lm	Square	1.75 mm
Cree LED CMB2550-R060-000N0U0A35H	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Warm White	3500 K	136 lm/W	6487 lm	Square	1.75 mm
Cree LED CMB2550-R060-00PN0U0A40G	Chip On Board (COB)	3.6 A	115 °	19 mm	90	34 V	Flat	23.85 mm	23.85 mm	85 °C	Neutral White	4000 K			Square	1.75 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	150	$ 11.22

Description

General part information

CMB2550 Series

LED Lighting COBs Engines Modules Chip On Board (COB) XLamp® CMB2550 White, Cool Square
