Q-7204W0008002M
ActiveMcGill Microwave Systems
COAX CBL RP-SMA TO TNC 6.6'
Q-7204W0008002M
ActiveMcGill Microwave Systems
COAX CBL RP-SMA TO TNC 6.6'
Description
General part information
Q-7204W0 Series
Cable Assembly Coaxial RP-SMA to TNC RG-58 78.7" (2.0m) 6.6'
Technical Specifications
Parameters and characteristics for this part
| Specification | Q-7204W0008002M |
|---|---|
| 1st Connector | RP-SMA Jack |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Male |
| 2nd Connector | Right Angle, TNC Plug |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Male |
| Cable Impedance | 50 Ohms |
| Cable Type | RG, 58 |
| Color | Black |
| Connector Impedance | 50 Ohms |
| Features | Shielded |
| Frequency - Max | 1 GHz |
| Length (ft) | 6.6 ft |
| Overall Impedance | 50 Ohms |
| Style | RP-SMA, TNC |
