4905CIR-0.75(5)

Active

3M (TC)

TAPE DBL SIDED CLR 3/4" DIA

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDate Code Decipher

4905CIR-0.75(5)

Active

3M (TC)

TAPE DBL SIDED CLR 3/4" DIA

Deep-Dive with AI

DocumentsDate Code Decipher

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	4905CIR-0.75(5)

Adhesive	Acrylic
Backing, Carrier	Polyester Film
Color	Clear
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature [Max]	100 °F, 38 °C
Storage/Refrigeration Temperature [Min]	40 °F, 4 °C
Tape Type	Double Coated, Double Sided
Temperature Range	200 °F
Temperature Range	93 °C
Thickness	0.508 mm
Thickness	0.02 in
Thickness	0.508 mm
Usage	General Purpose
Width	19.05 mm
Width	0.75 in
Width [diameter]	0.75 in

4905 Series

...

Part	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Shelf Life	Length	Length	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Color	Adhesive	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Shelf Life Start	Width	Width	Temperature Range	Temperature Range	Thickness	Thickness	Thickness	Tape Type	Width	Length	Width [x]	Width [x]	Usage	Width [y]	Width [y]	Backing, Carrier	Width [diameter]	Width	Length [x]	Length [x]
3M (TC) 3M 4905 8" X 10"-10	0.381 mm	15 mils	0.015 "	24 Months	10 in	254 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment	203.2 mm	8 in	93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided
3M (TC) 3M 4905 8" X 9"-10	0.381 mm	15 mils	0.015 "	24 Months	9 "	228.6 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment	203.2 mm	8 in	93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided
3M (TC) 4905-1.875-5	0.381 mm	15 mils	0.015 "	24 Months	15 ft	4.6 m	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment	47.63 mm	1.88 in	93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided	1 7/8"	5 yd
3M (TC) 3M 4905 9" X 9"-10	0.381 mm	15 mils	0.015 "	24 Months	9 "	228.6 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided			9 in	228.6 mm
3M (TC) 3M 4905 6" X 8"-10	0.381 mm	15 mils	0.015 "	24 Months	8 in	203.2 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided			6 in	152.4 mm
3M (TC) 4905-4-5				24 Months	15 ft	4.6 m				Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided		5 yd	4 "	101.6 mm	General Purpose
3M (TC) 4905-5-6(25)	0.381 mm	15 mils	0.015 "	24 Months	6 in	152.4 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided						127 mm	5 in
3M (TC) 3M 4905 5" X 8"-25	0.381 mm	15 mils	0.015 "	24 Months	8 in	203.2 mm	0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided						127 mm	5 in
3M (TC) 4905CIR-0.75(5)				24 Months						Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment	0.75 in		93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided					General Purpose			Polyester Film	0.75 in	19.05 mm
3M (TC) 3M 4905 3" X 4"-25	0.381 mm	15 mils	0.015 "	24 Months			0.005 "	5 mils	0.127 mm	Clear	Acrylic	4 °C 40 °F	38 °C 100 °F	Date of Shipment			93 °C	200 °F	0.508 mm	0.02 in	0.508 mm	Double Coated Double Sided			3 in	76.2 mm							101.6 mm	4 "

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	5	$ 13.95

Description

General part information

4905 Series

Double Coated, Double Sided Tape Acrylic Adhesive Clear 0.75" (19.05mm) 3/4" dia X

Documents

Technical documentation and resources
