2157603008
Connectors, Interconnects

2157603008

Active
Molex

MICRO-FIT+ RIGHT-ANGLE HEADER, THROUGH HOLE, 3.00MM PITCH, SINGLE ROW, 8 CIRCUITS, 0.76ΜM GOLD (AU) PLATING, GLOW-WIRE CAPABLE, BLACK

2157603008
Connectors, Interconnects

2157603008

Active
Molex

MICRO-FIT+ RIGHT-ANGLE HEADER, THROUGH HOLE, 3.00MM PITCH, SINGLE ROW, 8 CIRCUITS, 0.76ΜM GOLD (AU) PLATING, GLOW-WIRE CAPABLE, BLACK

Technical Specifications

Parameters and characteristics for this part

Specification2157603008
Connector TypeHeader
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thickness - Mating3 µin
Contact Length - Post0.125 in
Contact MaterialCopper Alloy
Contact ShapeSquare
Contact TypeMale Pin
Current Rating0 A
Current RatingVaries by Wire Gauge
Fastening TypeLocking Ramp
FeaturesGlow Wire Compliant, Board Lock
Insulation ColorBlack
Insulation Height0.173 in
Insulation MaterialGlass Filled, Liquid Crystal Polymer (LCP)
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole, Right Angle
Number of Positions8
Number of Positions LoadedAll
Number of Rows1
Operating Temperature (Max)105 °C
Operating Temperature (Min)-40 °C
Pitch - Mating0.118 in
ShroudingShrouded - 4 Wall
StyleCable/Wire, Board
TerminationSolder
Voltage Rating600 V
Voltage Rating (Type)DC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$Updated
DigikeyTray 1$ 4.61<6d
91$ 3.35
182$ 3.19
546$ 2.96
1001$ 2.83

CAD

3D models and CAD resources for this part

Description

General part information

215760 Series

Connector Header Through Hole, Right Angle 8 position 0.118" (3.00mm)
