5301FE 0081000

Active

Belden Inc.

CABLE 3CON 18AWG GRAY SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3CON 18AWG GRAY SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	5301FE 0081000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	4.34 mm
Jacket (Insulation) Diameter [diameter]	0.171 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.432 mm
Jacket (Insulation) Thickness	0.017 in
Jacket Color	Gray
Length	1000 ft
Length	304.8 m
Number of Conductors	3
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Commercial Audio
Wire Gauge	18 AWG

Part	Usage	Shield Coverage	Wire Gauge	Number of Conductors	Features	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Cable Type	Conductor Insulation	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Shield Material	Conductor Material	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Shield Type	Ratings	Voltage
Belden Inc. 5301FE 0081000	Commercial Audio	100 %	18 AWG	3	Rip Cord	26 AWG	7	1000 ft	304.8 m	Multi-Conductor	Polypropylene (PP)	4.34 mm	0.171 in	Gray	Aluminum	Copper Bare	Poly-Vinyl Chloride (PVC) Riser	0.432 mm	0.017 in	Foil
Belden Inc. 5301FE 008U1000	Security Sound	100 %	18 AWG	3	Drain Wire Rip Cord	26 AWG	7	1000 ft	304.8 m	Multi-Conductor	Polypropylene (PP)	4.34 mm	0.171 in	Gray	Aluminum	Copper Bare	Poly-Vinyl Chloride (PVC) Riser	0.432 mm	0.017 in	Foil	UL Style CMR	300 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Conductor Multi-Conductor Cable Gray 18 AWG Foil 1000.0' (304.8m)
