856-10-006-30-002000
ActiveMill-Max Manufacturing Corp.
CONN SPRING TARGET 6POS SMD
Deep-Dive with AI
Search across all available documentation for this part.
856-10-006-30-002000
ActiveMill-Max Manufacturing Corp.
CONN SPRING TARGET 6POS SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 856-10-006-30-002000 |
|---|---|
| Connector Type | Mating Target |
| Contact Finish | Gold |
| Contact Finish Thickness | 10 Áin |
| Contact Finish Thickness | 0.25 Ám |
| Material | Brass Alloy |
| Mounting Type | Surface Mount |
| Number of Contacts [custom] | 6 |
| Number of Rows | 1 |
| Pitch [x] | 0.05 in |
| Pitch [x] | 1.27 mm |
856-10 Series
| Part | Pitch [x] | Pitch [x] | Connector Type | Number of Contacts [custom] | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Finish | Material | Number of Contacts |
|---|---|---|---|---|---|---|---|---|---|---|---|
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 6 | 1 | 10 Áin | 0.25 Ám | Surface Mount Right Angle | Gold | Brass Alloy | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Through Hole | Gold | Brass Alloy | 10 | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Surface Mount | Gold | Brass Alloy | 5 | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 6 | 1 | 10 Áin | 0.25 Ám | Surface Mount | Gold | Brass Alloy | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 19 | 1 | 10 Áin | 0.25 Ám | Surface Mount Right Angle | Gold | Brass Alloy | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Through Hole | Gold | Brass Alloy | 12 | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Through Hole | Gold | Brass Alloy | 13 | |
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Surface Mount Right Angle | Gold | Brass Alloy | 9 | |
Mill-Max Manufacturing Corp. | Mating Target | 1 | 10 Áin | 0.25 Ám | Surface Mount Right Angle | Gold | Brass Alloy | 1 | |||
Mill-Max Manufacturing Corp. | 0.05 in | 1.27 mm | Mating Target | 1 | 10 Áin | 0.25 Ám | Surface Mount | Gold | Brass Alloy | 13 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 65 | $ 11.45 | |
Description
General part information
856-10 Series
6 Position Spring Mating Target Connector Surface Mount
Documents
Technical documentation and resources
No documents available
