1989557

Active

Phoenix Contact

FIXED TERMINAL BLOCKS PT 1.5/13-5.0-H BK

Search across all available documentation for this part.

Active

Phoenix Contact

FIXED TERMINAL BLOCKS PT 1.5/13-5.0-H BK

Technical Specifications

Parameters and characteristics for this part

Fixed Terminal Blocks PT 1.5/13-5.0-H BK

Part	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Max]	Torque - Screw [Min]	Number of Levels	Voltage	Wire Gauge [Max]	Wire Gauge [Min]	Current	Wire Termination	Mating Orientation	Housing Material	Pitch [x]	Pitch [x]	Positions Per Level	Screw Thread	Features	Mounting Type	Color
Phoenix Contact 1989557	3.5 Lb-In	3.1 Lb-In	0.4 Nm	0.35 Nm	1	300 V	26 AWG	12 AWG	18 A	Screw	Horizontal with Board	Polyamide (PA), Nylon	5 mm	0.197 in	13	M2.6	Interlocking (Side)	Through Hole	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fixed Terminal Blocks PT 1.5/13-5.0-H BK
