5300UP 005U500

Active

Belden Inc.

CABLE 2COND 18AWG GREEN

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 18AWG GREEN

Technical Specifications

Parameters and characteristics for this part

Specification	5300UP 005U500

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand	34 AWG, 42
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	4.67 mm
Jacket (Insulation) Diameter [diameter]	0.184 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.015 in
Jacket (Insulation) Thickness	0.381 mm
Jacket Color	Green
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	2
Usage	Commercial Audio
Voltage	300 V
Wire Gauge	18 AWG

Part	Conductor Material	Wire Gauge	Jacket Color	Jacket (Insulation) Material	Conductor Insulation	Voltage	Usage	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand	Features	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Number of Conductors	Length [x]	Length [x]	Length	Length
Belden Inc. 5300UP 005U500	Copper Bare	18 AWG	Green	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	300 V	Commercial Audio	Multi-Conductor	4.67 mm	0.184 in	34 AWG 42	Rip Cord	0.015 in	0.381 mm	2	500 '	152.4 m
Belden Inc. 5300UP D15U1000	Copper Bare	18 AWG	Blue	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	300 V	Commercial Audio	Multi-Conductor	4.67 mm	0.184 in	34 AWG 42	Rip Cord	0.015 in	0.381 mm	2			1000 ft	304.8 m
Belden Inc. 5300UP D151000	Copper Bare	18 AWG	Blue	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	300 V	Commercial Audio	Multi-Conductor	4.67 mm	0.184 in	34 AWG 42	Rip Cord	0.015 in	0.381 mm	2			1000 ft	304.8 m
Belden Inc. 5300UP 009U1000	Copper Bare	18 AWG		Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	300 V	Commercial Audio	Multi-Conductor	4.67 mm	0.184 in	34 AWG 42	Rip Cord	0.015 in	0.381 mm	2			1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

2 Conductor Multi-Conductor Cable Green 18 AWG 500.0' (152.4m)
