CIRCULAR CONNECTOR CONTACT, MOTIONGRADE™ M23 SERIES, PIN, CRIMP, 24 AWG, 28 AWG
SC000386
ActiveMcGill Microwave Systems
CIRCULAR CONNECTOR CONTACT, MOTIONGRADE™ M23 SERIES, PIN, CRIMP, 24 AWG, 28 AWG
Description
General part information
SC0003 Series
Pin Contact 24-28 AWG Size 1.0mm Crimp Gold
Technical Specifications
Parameters and characteristics for this part
| Specification | SC000386 |
|---|---|
| Contact Finish | Gold |
| Contact Material | Copper Alloy |
| Contact Size | 1 mm |
| Contact Termination | Crimp |
| Contact Type | Pin |
| Type | Machined |
| Wire Gauge or Range - AWG (Max) | 28 AWG |
| Wire Gauge or Range - AWG (Min) | 24 AWG |
