EB2-5NU

Active

KEMET

RELAY GENERAL PURPOSE DPDT 1A 5V

Search across all available documentation for this part.

Active

KEMET

RELAY GENERAL PURPOSE DPDT 1A 5V

Technical Specifications

Parameters and characteristics for this part

Part	Coil Voltage	Load - Max Switching	Mounting Type	Coil Type	Approval Agency	Operate Time	Contact Form	Switching Voltage	Operating Temperature [Max]	Operating Temperature [Min]	Release Time	Relay Type	Coil Resistance	Termination Style	Must Release Voltage	Must Operate Voltage	Contact Rating (Current)	Contact Material
KEMET EB2-5NU	5 VDC	220 W 250 VA	Surface Mount	Non Latching	CSA UR	2 ms	DPDT (2 Form C)	220 VDC 250 VAC	85 °C	-40 °C	1 ms	General Purpose	178 Ohms	Gull Wing	0.5 VDC	3.75 VDC	1 A	Gold Alloy Silver Alloy
KEMET EB2-5NU-L	5 VDC	220 W 250 VA	Surface Mount	Non Latching	CSA UR	2 ms	DPDT (2 Form C)	220 VDC 250 VAC	85 °C	-40 °C	1 ms	General Purpose	178 Ohms	Gull Wing	0.5 VDC	3.75 VDC	1 A	Gold Alloy Silver Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay DPDT (2 Form C) Surface Mount
