TE Connectivity-3-641218-4 Connector Headers and PCB Receptacles Conn IDC Connector F 4 POS 3.96mm IDT RA Cable Mount Bag/Box

3-641218-4

Active
TE Connectivity AMP Connectors

CONN IDC CONNECTOR F 4 POS 3.96MM IDT RA CABLE MOUNT BAG/BOX

Find alt
TE Connectivity-3-641218-4 Connector Headers and PCB Receptacles Conn IDC Connector F 4 POS 3.96mm IDT RA Cable Mount Bag/Box

3-641218-4

Active
TE Connectivity AMP Connectors

CONN IDC CONNECTOR F 4 POS 3.96MM IDT RA CABLE MOUNT BAG/BOX

Find alt

Description

General part information

641218 Series

4 Position, Receptacle, Connector Assembly, Insulation Displacement (IDC), Wire-to-Board, Tin (Sn), UL 94V-2, 3.96 mm [.156 in] Centerline, MTA 156

Technical Specifications

Parameters and characteristics for this part

Specification3-641218-4
Cable TerminationIDC
ColorYellow
Connector TypeReceptacle
Contact FinishGold
Contact Finish Thickness30 µin
Contact TypeFemale Socket
Fastening TypeLocking Ramp
FeaturesClosed End
Mounting TypeFree Hanging (In-Line)
Number of Positions4
Number of Rows1
Pitch0.156 in
Wire Gauge20 AWG
Wire TypeRibbon Cable, Discrete
