Specification	IVU2PRGW12

Features	Software Included
Image Type	Monochrome
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Light Source Color	White
Light Source Type	Integrated
Mounting Type	Chassis Mount
Operating Temperature (Max)	40 °C
Operating Temperature (Min)	0 °C
Resolution (Megapixels)	0.4 MP
Resolution Height	480
Resolution Total Pixels	360960 Pixels
Resolution Width	752 px
Sensor Type	CMOS
Termination Style	Cable with Connector
Type	Imaging Camera
Voltage - Supply (Maximum)	30 VDC
Voltage - Supply (Minimum)	10 VDC

IVU2PR Series

Part	Light Source Type	Light Source Color	Mounting Type	Termination Style	Resolution Height	Resolution Total Pixels	Resolution Width	Resolution (Megapixels)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Operating Temperature (Max)	Features	Type	Ingress Protection Description	Ingress Protection IP Rating	Sensor Type	Image Type	Light Source
BANNER ENGINEERING IVU2PRCW08	Integrated	White	Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Color
BANNER ENGINEERING IVU2PRGW12	Integrated	White	Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome
BANNER ENGINEERING IVU2PRGX06			Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome
BANNER ENGINEERING IVU2PRGX25			Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome
BANNER ENGINEERING IVU2PRBR06			Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome	Integrated (Red)
BANNER ENGINEERING IVU2PRGI08	Integrated	Infrared	Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome
BANNER ENGINEERING IVU2PRGR12			Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome	Integrated (Red)
BANNER ENGINEERING IVU2PRGR16			Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome	Integrated (Red)
BANNER ENGINEERING IVU2PRGW08	Integrated	White	Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome
BANNER ENGINEERING IVU2PRGI12	Integrated	Infrared	Chassis Mount	Cable with Connector	480	360960 Pixels	752 px	0.4 MP	30 VDC	10 VDC	40 °C	Software Included	Imaging Camera	Dust Tight Waterproof	IP67	CMOS	Monochrome

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

IVU2PRGW12 | Datasheet
