M85049/11-33N

Active

Amphenol Interconnect India

CONN BACKSH W/CLMP SZ20 37 SIL

Search across all available documentation for this part.

Active

Amphenol Interconnect India

CONN BACKSH W/CLMP SZ20 37 SIL

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Silver Connector Backshell, Cable Clamp 20, 37

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

Specification	M85049/11-33N	M85049/11 Series

Cable Exit	180 °	180 °
Cable Opening	-	0.31 - 0.63 in
Cable Opening	-	0.13 - 0.35 in
Cable Opening	-	7.87 - 16 mm
Cable Opening	-	3.3 - 8.89 mm
Cable Opening [custom]	12.7 mm, 19.05 mm	12.7 - 19.05 mm
Cable Opening [custom]	0.5 in, 0.75 in	0.5 - 0.75 in
Color	Silver	Black, Silver
Diameter - Outside [diameter]	1.345 "	1.11 - 2.72 "
Diameter - Outside [diameter]	34.16 mm	28.19 - 69.09 mm
Features	Clamp Screws	Clamp Screws
For Use With/Related Products	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III
Ingress Protection	Environment Resistant	Environment Resistant
Material	Aluminum Alloy	Aluminum Alloy
Plating	Electroless Nickel	Zinc Cobalt, Electroless Nickel
Shell Size - Insert	37, 20	16 - 40
Shielding	Unshielded	Unshielded
Type	Backshell, Cable Clamp	Backshell, Cable Clamp

CONN BACKSHELL W/CLMP SZ22 BLACK

Part	Material	Features	For Use With/Related Products	Shell Size - Insert	Shielding	Plating	Color	Type	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Ingress Protection	Cable Exit	Cable Opening [custom]	Cable Opening [custom]
Amphenol Interconnect India M85049/11-40Z	Aluminum Alloy	Clamp Screws	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III	22	Unshielded	Zinc Cobalt	Black	Backshell, Cable Clamp	0.63 in	0.35 in	16 mm	8.89 mm	1.47 "	37.34 mm	Environment Resistant	180 °
Amphenol Interconnect India M85049/11-135Z	Aluminum Alloy	Clamp Screws	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III	40	Unshielded	Zinc Cobalt	Black	Backshell, Cable Clamp					2.72 "	69.09 mm	Environment Resistant	180 °
Amphenol Interconnect India M85049/11-153Z	Aluminum Alloy	Clamp Screws	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III	16, 19	Unshielded	Zinc Cobalt	Black	Backshell, Cable Clamp	0.31 in	0.13 in	7.87 mm	3.3 mm	1.11 in	28.19 mm	Environment Resistant	180 °
Amphenol Interconnect India M85049/11-33N	Aluminum Alloy	Clamp Screws	MIL-DTL-26482 Series II, MIL-DTL-5015, MIL-DTL-83723 Series III	20, 37	Unshielded	Electroless Nickel	Silver	Backshell, Cable Clamp					1.345 "	34.16 mm	Environment Resistant	180 °	12.7 mm, 19.05 mm	0.5 in, 0.75 in
