SD1488

Obsolete

STMicroelectronics

RF TRANS NPN 16V M111

Search across all available documentation for this part.

Obsolete

STMicroelectronics

RF TRANS NPN 16V M111

Technical Specifications

Parameters and characteristics for this part

Specification	SD1488

Current - Collector (Ic) (Max) [Max]	8 A
DC Current Gain (hFE) (Min) @ Ic, Vce	20 hFE
Gain	5.8 dB
Mounting Type	Surface Mount
Operating Temperature	200 °C
Package / Case	M111
Power - Max [Max]	117 W
Supplier Device Package	M111
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	16 V

Part	Supplier Device Package	Transistor Type	Operating Temperature	Mounting Type	Package / Case	Current - Collector (Ic) (Max) [Max]	Power - Max [Max]	Gain	DC Current Gain (hFE) (Min) @ Ic, Vce	Voltage - Collector Emitter Breakdown (Max)
STMicroelectronics SD1488	M111	NPN	200 °C	Surface Mount	M111	8 A	117 W	5.8 dB	20 hFE	16 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RF Transistor NPN 16V 8A 117W Surface Mount M111
