AZ576-1A-24DE

Active

American Zettler

RELAY GEN PURPOSE SPST 20A 24V

Search across all available documentation for this part.

Active

American Zettler

RELAY GEN PURPOSE SPST 20A 24V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY GEN PURPOSE SPST 20A 12V

Part	Release Time	Coil Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Must Release Voltage	Contact Form	Must Operate Voltage	Coil Insulation	Switching Voltage	Termination Style	Approval Agency	Seal Rating	Relay Type	Load - Max Switching	Operate Time	Coil Type	Contact Material	Contact Rating (Current)	Coil Resistance	Mounting Type	Coil Current
American Zettler AZ576-1A-12DE	8 ms	12 VDC	-40 °C	105 ░C	1.2 VDC	SPST-NO (1 Form A)	9 VDC	Class F	30 VDC, 480 VAC	PC Pin	cUR, TUV, UL	Sealed - Fully	General Purpose	510 W, 5540 VA	15 ms	Non Latching	Silver Tin Oxide (AgSnO)	20 A	360 Ohms	Through Hole	33.3 mA
American Zettler AZ576-1A-24DE	8 ms	24 VDC	-40 °C	105 ░C	2.4 VDC	SPST-NO (1 Form A)	18 VDC	Class F	30 VDC, 480 VAC	PC Pin	cUR, TUV, UL	Sealed - Fully	General Purpose	510 W, 5540 VA	15 ms	Non Latching	Silver Tin Oxide (AgSnO)	20 A	1440 Ohms	Through Hole	16.7 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
