XT314012

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 16A 12V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 16A 12V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

General Purpose Relay SPDT (1 Form C) 12VDC Coil Socketable

Technical documentation and resources

Parameters and characteristics commom to parts in this series

RELAY GEN PURPOSE SPDT 16A 115V

Part	Must Release Voltage	Termination Style	Release Time	Operate Time	Mounting Type	Coil Current	Operating Temperature [Min]	Operating Temperature [Max]	Coil Insulation	Coil Type	Must Operate Voltage	Coil Resistance	Contact Material	Contact Form	Relay Type	Switching Voltage [Max]	Load - Max Switching	Approval Agency	Coil Voltage	Contact Rating (Current)
TE Connectivity Potter & Brumfield Relays 1887101-7	17.3 VAC	Plug In	6 ms	9 ms	Socketable	6.6 mA	-40 °C	70 °C	Class F	Non Latching	86.3 VAC	8.1 kOhms	Silver Nickel (AgNi)	SPDT (1 Form C)	General Purpose	400 VAC	6400 VA	cURus, VDE	115 VAC	16 A
TE Connectivity Potter & Brumfield Relays 1887100-3	2.4 VDC	Plug In	6 ms	9 ms	Socketable	16.7 mA	-40 °C	70 °C	Class F	Non Latching	16.8 VDC	1440 Ohms	Silver Nickel (AgNi)	SPDT (1 Form C)	General Purpose	400 VAC	6400 VA	cURus, VDE	24 VDC	16 A
TE Connectivity Potter & Brumfield Relays 1887103-1	34.5 VAC	PC Pin	6 ms	8 ms	Through Hole	16.7 mA	-40 °C	70 °C	Class F	Non Latching	184 VAC	32500 Ohms	Silver Nickel (AgNi)	SPDT (1 Form C)	General Purpose	400 VAC	6400 VA	cURus, VDE	230 VAC	16 A
TE Connectivity Potter & Brumfield Relays XT314012	1.2 VDC	Plug In	6 ms	9 ms	Socketable	16.7 mA	-40 °C	70 °C	Class F	Non Latching	8.4 VDC	360 Ohms	Silver Nickel (AgNi)	SPDT (1 Form C)	General Purpose	400 VAC	6400 VA	cURus, VDE	12 VDC	16 A
