5-1445455-2

Obsolete

TE Connectivity Raychem Cable Protection

TERM SCREW M3.5 4 PIN PCB RA

Search across all available documentation for this part.

Obsolete

TE Connectivity Raychem Cable Protection

TERM SCREW M3.5 4 PIN PCB RA

Technical Specifications

Parameters and characteristics for this part

Specification	5-1445455-2

Contact Finish	Tin-Lead
Contact Material	Copper Alloy
Material - Insulation	Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type	Through Hole, Right Angle
Number of Pins	4
Screw Finish	Nickel
Screw Material	Steel
Screw Size	M3.5
Terminal Type	Screw Terminal, Power Tap
Termination	Solder

Part	Terminal Type	Contact Material	Termination	Material - Insulation	Screw Size	Number of Pins	Mounting Type	Screw Finish	Contact Finish	Screw Material
TE Connectivity Raychem Cable Protection 5-1445455-2	Power Tap Screw Terminal	Copper Alloy	Solder	Polybutylene Terephthalate (PBT) Glass Filled	M3.5	4	Through Hole Right Angle	Nickel	Tin-Lead	Steel

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

4 Pin Screw Terminal, Power Tap M3.5 Through Hole, Right Angle

Technical documentation and resources

No documents available
