MAXM17514EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAXM17514
Deep-Dive with AI
Search across all available documentation for this part.
MAXM17514EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR MAXM17514
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM17514EVKIT# | MAXM17514 Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 4 A | 4 A |
| Current - Output (Max) | - | 4 A |
| Features | - | OTP, UVLO, OCP |
| Frequency - Switching | 1 MHz | 1 MHz |
| Main Purpose | DC/DC, Step Down | DC/DC, Step Down |
| Mounting Type | - | Surface Mount |
| Number of Outputs | - | 1 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Outputs and Type | Non-Isolated | Non-Isolated |
| Outputs and Type | 1 | 1 |
| Package / Case | - | 29-SMD Module, Exposed Pad |
| Regulator Topology | Buck | Buck |
| Size / Dimension | - | 10 mm |
| Size / Dimension | - | 0.39 " |
| Size / Dimension | - | 0.3 " |
| Size / Dimension | - | 0.07 " |
| Size / Dimension | - | 1.9 mm |
| Size / Dimension | - | 7.5 mm |
| Supplied Contents | Board(s) | Board(s) |
| Type | - | Non-Isolated PoL Module |
| Utilized IC / Part | MAXM17514 | MAXM17514 |
| Voltage - Input (Max) | - | 5.5 V |
| Voltage - Input (Min) | - | 2.4 V |
| Voltage - Input [Max] | 5.5 V | 5.5 V |
| Voltage - Input [Min] | 2.4 V | 2.4 V |
| Voltage - Output [Max] | 3.6 V | 3.6 V |
| Voltage - Output [Min] | 0.75 V | 0.75 V |
| Voltage - Output 1 | - | 0.75 V |
| Voltage - Output 1 | - | 3.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 41.05 | |
MAXM17514 Series
EVAL KIT FOR MAXM17514
| Part | Board Type | Utilized IC / Part | Frequency - Switching | Voltage - Input [Min] | Voltage - Input [Max] | Main Purpose | Regulator Topology | Voltage - Output [Min] | Voltage - Output [Max] | Supplied Contents | Outputs and Type | Outputs and Type | Current - Output | Voltage - Input (Max) [Max] | Applications | Current - Output (Max) [Max] | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Voltage - Input (Min) [Min] | Features | Operating Temperature [Max] | Operating Temperature [Min] | Type | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Mounting Type | Package / Case | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM17514EVKIT# | Fully Populated | MAXM17514 | 1 MHz | 2.4 V | 5.5 V | DC/DC, Step Down | Buck | 0.75 V | 3.6 V | Board(s) | Non-Isolated | 1 | 4 A | |||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17514ALI+T | 5.5 V | ITE (Commercial) | 4 A | 0.75 V | 3.6 V | 2.4 V | OCP, OTP, UVLO | 125 °C | -40 °C | Non-Isolated PoL Module | 10 mm | 0.39 " | 0.3 " | 0.07 " | 1.9 mm | 7.5 mm | Surface Mount | 29-SMD Module, Exposed Pad | 1 |
