BQ24640EVM
ActiveEVAL MODULE FOR BQ24640
Deep-Dive with AI
Search across all available documentation for this part.
BQ24640EVM
ActiveEVAL MODULE FOR BQ24640
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24640EVM | BQ24640 Series |
|---|---|---|
| Applications | - | Supercapacitor Charger |
| Contents | Board(s) | Board(s) |
| Current - Supply | - | 1 mA |
| Embedded | False | False |
| Function | Battery Charger | Battery Charger |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 85 °C |
| Package / Case | - | 16-VFQFN Exposed Pad |
| Primary Attributes | 26 V | 26 V |
| Primary Attributes | Multi Cell-Li-ion / Li-Polymer | Multi Cell-Li-ion / Li-Polymer |
| Secondary Attributes | On-Board LEDs | On-Board LEDs |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 3.5 |
| Supplier Device Package | - | 3.5 |
| Supplier Device Package | - | 16-VQFN |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24640 | BQ24640 |
| Voltage - Supply | - | 28 V |
| Voltage - Supply | - | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 118.80 | |
BQ24640 Series
Standalone 1-8 cell Buck battery charge controller for super capacitor
| Part | Voltage - Supply [Max] | Voltage - Supply [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Applications | Current - Supply | Supplier Device Package [x] | Supplier Device Package [y] | Supplier Device Package | Package / Case | Contents | Embedded | Primary Attributes | Primary Attributes | Utilized IC / Part | Function | Secondary Attributes | Supplied Contents | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24640RVAT | 28 V | 5 V | -40 °C | 85 °C | Surface Mount | Supercapacitor Charger | 1 mA | 3.5 | 3.5 | 16-VQFN | 16-VFQFN Exposed Pad | |||||||||
Texas Instruments BQ24640EVM | Board(s) | 26 V | Multi Cell-Li-ion / Li-Polymer | BQ24640 | Battery Charger | On-Board LEDs | Board(s) | Power Management |
Description
General part information
BQ24640 Series
The bq24640 device is a highly integrated switched-mode super capacitor charge controller. The device offers a constant-frequency synchronous PWM controller with high accuracy charge current, voltage regulation, and charge status monitoring.
The bq24640 charges a super capacitor in two phases: constant current and constant voltage (CC/CV). The device can charge super capacitors from 0 V with current set on the ISET pin. When the super capacitor voltage reaches the programmed target voltage, charge current begins tapering down.
The bq24640 enters a low-current sleep mode(<15 µA) when the input voltage falls below the output capacitor voltage.
