PI3106-01-EVAL1

Obsolete

Vicor Corporation

EVAL BOARD FOR PI3106-01-HVIZ

Search across all available documentation for this part.

Obsolete

Vicor Corporation

EVAL BOARD FOR PI3106-01-HVIZ

Technical Specifications

Parameters and characteristics for this part

Part	Supplied Contents	Utilized IC / Part	Voltage - Output	Outputs and Type	Outputs and Type	Current - Output	Main Purpose	Power - Output	Voltage - Input [Max]	Voltage - Input [Min]	Frequency - Switching	Board Type	Regulator Topology	Voltage - Input (Max) [Max]	Standard Number	Number of Outputs	Approval Agency	Features	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Power (Watts)	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Efficiency	Voltage - Input (Min) [Min]	Type	Voltage - Isolation	Package / Case	Current - Output (Max) [Max]
Vicor Corporation PI3106-01-EVAL1	Board(s)	PI3106-01	12 V	Isolated	1	4.2 A	DC/DC Step Down	50 W	36 V	18 V	900 kHz	Fully Populated	Buck
Vicor Corporation PI3106-00-HVIZ														50 V	60950-1	1	CSA	Adjustable Output Remote On/Off	12 V	6.7 mm	22 mm	0.65 in	0.87 in	16.5 mm	0.26 "	50 W	Surface Mount	-55 °C	125 °C	ITE (Commercial)	88 %	16 V	Isolated Module	2250 VDC	8-SMD Module	4.17 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

PI3106-01 - DC/DC, Step Down 1, Isolated Outputs Evaluation Board
