IJ5-08-05.0-L-S-1-TR
ActiveSamtec Inc.
CONTACT ARRARY ASSEMBLY
Deep-Dive with AI
Search across all available documentation for this part.
IJ5-08-05.0-L-S-1-TR
ActiveSamtec Inc.
CONTACT ARRARY ASSEMBLY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | IJ5-08-05.0-L-S-1-TR |
|---|---|
| Center Contact Material | Copper Alloy |
| Center Contact Plating | Gold |
| Connector Type | Male Pin, Jack |
| Contact Termination | Solder |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Frequency - Max [Max] | 9.5 GHz |
| Housing Color | Black |
| Impedance | 50 Ohms |
| Insertion Loss | 3 dB |
| Mounting Type | Surface Mount |
| Number of Ports | 8 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Voltage Rating | 200 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 16.36 | |
| 10 | $ 15.58 | |||
| 25 | $ 14.84 | |||
| 50 | $ 14.13 | |||
| 100 | $ 13.55 | |||
| Digi-Reel® | 1 | $ 16.36 | ||
| 10 | $ 15.58 | |||
| 25 | $ 14.84 | |||
| 50 | $ 14.13 | |||
| 100 | $ 13.55 | |||
| Tape & Reel (TR) | 275 | $ 13.55 | ||
Description
General part information
IJ5-08 Series
Connector Jack, Male Pin 50 Ohms Surface Mount Solder
