AV35049

Obsolete

Panasonic Electric Works

SWITCH SNAP ACTION SPDT 3A 125V

Search across all available documentation for this part.

Obsolete

Panasonic Electric Works

SWITCH SNAP ACTION SPDT 3A 125V

Technical Specifications

Parameters and characteristics for this part

Part	Operating Position	Operating Position	Switch Function	Differential Travel	Differential Travel	Voltage Rating - DC	Current Rating (Amps)	Voltage Rating - AC	Circuit	Mechanical Life	Pretravel	Pretravel	Electrical Life	Termination Style	Overtravel	Overtravel	Mounting Type	Release Force	Operating Force	Actuator Type	Operating Temperature [Min]	Operating Temperature [Max]
Panasonic Electric Works AV35049	8.4 mm	0.33 in	On-Mom	0.1 mm	0.004 in	30 V	3 A	125 V	SPDT	500000 Cycles	0.024 in	0.6 mm	50000 Cycles	PC Pin	0.4 mm	0.015 "	Through Hole	15 gf	100 gf	Round (Pin Plunger)	-25 °C	85 °C
Panasonic Electric Works AV3504619	8.4 mm	0.33 in	On-Mom	0.1 mm	0.004 in	30 V	100 mA	125 V	SPDT	500000 Cycles	0.024 in	0.6 mm	200000 Cycles	PC Pin	0.4 mm	0.015 "	Through Hole	15 gf	100 gf	Round (Pin Plunger)	-25 °C	85 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Switch SPDT Through Hole
