A17747-16

Active

Laird Technologies - Thermal Materials

THERM PAD 228.6MMX228.6MM PURP

Deep-Dive with AI

Search across all available documentation for this part.

A17747-16

Active

Laird Technologies - Thermal Materials

THERM PAD 228.6MMX228.6MM PURP

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	A17747-16

Backing, Carrier	Polyimide
Color	Purple
Material	Elastomer
Outline [x]	228.6 mm
Outline [y]	228.6 mm
Shape	Square
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Thermal Conductivity	3 W/m-K
Thickness	0.16 in
Thickness	4.06 mm
Type	Gap Filler Pad, Sheet

A17747 Series

Part	Color	Backing, Carrier	Material	Shape	Outline [x]	Outline [y]	Shelf Life	Type	Thermal Conductivity	Shelf Life Start	Thickness	Thickness	Thickness [z]	Thickness [z]	Thickness [custom]
Laird Technologies - Thermal Materials A17747-16	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.16 in	4.06 mm
Laird Technologies - Thermal Materials A17747-15	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.15 in	3.81 mm
Laird Technologies - Thermal Materials A17747-05	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.05 in	50 mils
Laird Technologies - Thermal Materials A17747-20	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.2 in	200 mils
Laird Technologies - Thermal Materials A17747-11	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment			2.79 mm	0.11 in
Laird Technologies - Thermal Materials A17747-10	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.1 in	2.54 mm
Laird Technologies - Thermal Materials A17747-19	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment		4.83 mm			0.19 in
Laird Technologies - Thermal Materials A17747-02	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.02 in	0.508 mm
Laird Technologies - Thermal Materials A17747-07	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.07 in	1.778 mm
Laird Technologies - Thermal Materials A17747-09	Purple	Polyimide	Elastomer	Square	228.6 mm	228.6 mm	24 Months	Gap Filler Pad Sheet	3 W/m-K	Date of Shipment	0.09 in	2.286 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 195.30

Description

General part information

A17747 Series

Thermal Pad Purple 228.60mm x 228.60mm Square

Documents

Technical documentation and resources

No documents available
