RN212-3.6-02-0M4

Active

TE Connectivity Raychem Cable Protection

CMC 400UH 3.6A 2LN TH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

RN212-3.6-02-0M4

Active

TE Connectivity Raychem Cable Protection

CMC 400UH 3.6A 2LN TH

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RN212-3.6-02-0M4

Approval Agency	ENEC, UR, VDE
Current Rating (Max) [Max]	3.6 A
DC Resistance (DCR) (Max)	27 mOhm
Filter Type	Power Line
Height (Max) [Max]	0.799 "
Height (Max) [Max]	20.3 mm
Inductance @ Frequency	400 µH, 10 kHz
Mounting Type	Through Hole
Number of Lines	2
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Package / Case	4 Lead
Package / Case	Vertical
Size / Dimension [x]	18 mm
Size / Dimension [x]	0.709 in
Size / Dimension [y]	0.492 "
Size / Dimension [y]	12.5 mm
Voltage Rating - AC	300 V

Schaffner RN-Series Series

Part	Inductance @ Frequency	Operating Temperature [Max]	Operating Temperature [Min]	Number of Lines	Approval Agency	Filter Type	Size / Dimension [custom]	Size / Dimension [diameter]	Size / Dimension [custom]	Size / Dimension [diameter]	Voltage Rating - AC	Package / Case	Package / Case	Height (Max) [Max]	Height (Max) [Max]	Current Rating (Max) [Max]	DC Resistance (DCR) (Max)	Mounting Type	Height (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [Max] [z]	Height (Max) [Max] [z]	Height (Max)
TE Connectivity Raychem Cable Protection RN102-0.3-02-12M	12 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line	0.551 "	0.551 in	14 mm	14 mm	300 V	Horizontal	4 Lead	9.3 mm	0.366 in	300 mA	1.1 Ohm	Through Hole
TE Connectivity Raychem Cable Protection RN142-0.5-02-82M	10 kHz 82 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Horizontal	4 Lead		20 mm	500 mA	2.7 Ohm	Through Hole	0.787 in	1.28 in	1.303 in	32.5 mm	33.1 mm
TE Connectivity Raychem Cable Protection RN216-0.5-02-47M	10 kHz 47 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Vertical	4 Lead			500 mA	960 mOhm	Through Hole		0.61 in	0.906 in	15.5 mm	23 mm	0.996 in	25.3 mm
TE Connectivity Raychem Cable Protection RN112-1.5-02-3M3	3.3 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Horizontal	4 Lead			1.5 A	102 mOhm	Through Hole	0.508 in	0.673 in	0.697 in	17.1 mm	17.7 mm			12.9 mm
TE Connectivity Raychem Cable Protection RN112-0.5-02-15M	10 kHz 15 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Horizontal	4 Lead			500 mA	700 mOhm	Through Hole	0.508 in	0.673 in	0.697 in	17.1 mm	17.7 mm			12.9 mm
TE Connectivity Raychem Cable Protection RN202-0.6-02-4M4	4.4 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Vertical	4 Lead		13.8 mm	600 mA	380 mOhm	Through Hole	0.543 in	0.346 in	0.717 in	8.8 mm	18.2 mm
TE Connectivity Raychem Cable Protection RN212-3.6-02-0M4	10 kHz 400 µH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Vertical	4 Lead		20.3 mm	3.6 A	27 mOhm	Through Hole	0.799 "	0.492 "	0.709 in	12.5 mm	18 mm
TE Connectivity Raychem Cable Protection RN142-4-02-3M3	3.3 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Horizontal	4 Lead		20 mm	4 A	67 mOhm	Through Hole	0.787 in	1.28 in	1.303 in	32.5 mm	33.1 mm
TE Connectivity Raychem Cable Protection RN242-1-02-33M	10 kHz 33 mH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Vertical	4 Lead		34.6 mm	1 A		Through Hole	1.362 in	0.709 "	1.22 in	18 mm	31 mm
TE Connectivity Raychem Cable Protection RN112-2.6-02-0M4	10 kHz 400 µH	100 °C	-40 °C	2	ENEC UR VDE	Power Line					300 V	Horizontal	4 Lead			2.6 A	40 mOhm	Through Hole	0.508 in	0.673 in	0.697 in	17.1 mm	17.7 mm			12.9 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 1.60
		10	$ 1.24
		25	$ 1.12
		50	$ 1.04
		100	$ 0.97

Description

General part information

Schaffner RN-Series Series

400 µH @ 10 kHz 2 Line Common Mode Choke Through Hole 3.6A DCR 27mOhm (Typ)
