TLE4269GMXUMA2
THE OPTIREG™ LINEAR TLE4269GM IS AN AUTOMOTIVE VOLTAGE REGULATOR WITH A 5 V FIXED OUTPUT IN A PG‑DSO‑14 PACKAGE. THE MAXIMUM OPERATING VOLTAGE IS 45 V.
Deep-Dive with AI
Search across all available documentation for this part.
TLE4269GMXUMA2
THE OPTIREG™ LINEAR TLE4269GM IS AN AUTOMOTIVE VOLTAGE REGULATOR WITH A 5 V FIXED OUTPUT IN A PG‑DSO‑14 PACKAGE. THE MAXIMUM OPERATING VOLTAGE IS 45 V.
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | TLE4269GMXUMA2 |
|---|---|
| Control Features | Reset |
| Current - Output | 150 mA |
| Current - Quiescent (Iq) | 300 µA |
| Current - Supply (Max) [Max] | 8 mA |
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Positive |
| Output Type | 1.81 mOhm |
| Package / Case | 14-SOIC |
| Package / Case [x] | 0.154 in |
| Package / Case [y] | 3.9 mm |
| Protection Features | Reverse Polarity, Over Temperature, Short Circuit |
| Qualification | AEC-Q100 |
| Supplier Device Package | PG-DSO-14-61 |
| Voltage - Input (Max) [Max] | 45 V |
| Voltage - Output (Min/Fixed) | 5 V |
| Voltage Dropout (Max) [Max] | 0.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.50 | |
| 10 | $ 2.25 | |||
| 25 | $ 2.12 | |||
| 100 | $ 1.81 | |||
| 250 | $ 1.70 | |||
| 500 | $ 1.48 | |||
| 1000 | $ 1.23 | |||
| Digi-Reel® | 1 | $ 2.50 | ||
| 10 | $ 2.25 | |||
| 25 | $ 2.12 | |||
| 100 | $ 1.81 | |||
| 250 | $ 1.70 | |||
| 500 | $ 1.48 | |||
| 1000 | $ 1.23 | |||
| Tape & Reel (TR) | 2500 | $ 1.14 | ||
| 5000 | $ 1.10 | |||
Description
General part information
TLE4269 Series
TLE4269GMXUMA2 is an automotive voltage regulator with a 5V fixed output. The maximum operating voltage is 45V. The output is able to drive 150mA load. This device features short-circuit protection. The thermal shutdown feature switches the output off when the junction temperature exceeds 150°C to ensure the device is not damaged by overheating. A reset signal is generated when the output voltage drops below VQ <4.65V. The reset threshold voltage can be decreased by an external connection of a voltage divider. The reset delay time can be set by an external capacitor. Reset and sense output have integrated pull-up resistors. If the integrated resistors are not required, the TLE4279 can be used instead. It is also possible to supervise the input voltage by using an integrated comparator to give a low voltage warning. Potential applications include general automotive applications.
