FN420-4-13
NRNDTE Connectivity Raychem Cable Protection
LINE FILTER 250VAC 4A CHASSIS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN420-4-13 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CSA, ENEC, UR |
| Configuration | Single Stage |
| Current | 4 A |
| Filter Type | Single Phase |
| Frequency - Operating | 400 Hz |
| Inductance | 2 mH |
| Mounting Type | Chassis Mount |
| Termination Style | Quick Connect |
| Voltage - Rated AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 23.57 | |
| 10 | $ 19.22 | |||
| 25 | $ 17.72 | |||
| 40 | $ 17.00 | |||
| 80 | $ 15.99 | |||
| 230 | $ 15.35 | |||
Description
General part information
FN420 Series
Single Phase EMC/EMI Line Filter 4 A 250V DC ~ 400Hz Single Stage Quick Connect
