14UL1015STRBLA250

Active

Remington Industries

HOOK-UP STRND 14AWG BLACK 250'

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

14UL1015STRBLA250

Active

Remington Industries

HOOK-UP STRND 14AWG BLACK 250'

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	14UL1015STRBLA250

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	41
Conductor Strand [custom]	30 AWG
Features	Chemical Resistant, Oil Resistant, Abrasion Resistant, Solvent Resistant
Jacket (Insulation) Diameter [diameter]	0.141 in
Jacket (Insulation) Diameter [diameter]	3.58 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.76 mm
Jacket (Insulation) Thickness	0.762 mm
Jacket Color	Black
Length	3000 "
Length	76.2 m
Operating Temperature	105 C
Voltage	600 V
Wire Gauge	13.5 AWG

14UL1015 Series

Part	Wire Gauge	Jacket Color	Operating Temperature	Features	Conductor Material	Voltage	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]	Jacket (Insulation) Material	Length	Length	Kit Type	Kit Type	Values
Remington Industries 14UL1015STRRED500	13.5 AWG	Red	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm	500 '	152.4 m	Poly-Vinyl Chloride (PVC)
Remington Industries 14UL1015STRYEL100	13.5 AWG	Yellow	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm	100 ft	30.5 m	Poly-Vinyl Chloride (PVC)
Remington Industries 14UL1015STRBLU100	13.5 AWG	Blue	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm	100 ft	30.5 m	Poly-Vinyl Chloride (PVC)
Remington Industries 14UL1015STRORA100	13.5 AWG	Orange	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm	100 ft	30.5 m	Poly-Vinyl Chloride (PVC)
Remington Industries 14UL1015STRBRO250	13.5 AWG	Brown	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm			Poly-Vinyl Chloride (PVC)	3000 "	76.2 m
Remington Industries 14UL1015STRBLA250	13.5 AWG	Black	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm			Poly-Vinyl Chloride (PVC)	3000 "	76.2 m
Remington Industries 14UL1015STRYEL250	13.5 AWG	Yellow	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm			Poly-Vinyl Chloride (PVC)	3000 "	76.2 m
Remington Industries 14UL1015STRGRA1000	13.5 AWG	Gray	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm			Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m
Remington Industries 14UL1015STRKIT10COLOR100																			Hook Up Wire	14 AWG	10 pcs 100 ft
Remington Industries 14UL1015STRBLA100	13.5 AWG	Black	105 C	Abrasion Resistant Chemical Resistant Oil Resistant Solvent Resistant	Copper Tinned	600 V	Hook-Up	0.141 in	3.58 mm	41	30 AWG	0.76 mm	0.762 mm	100 ft	30.5 m	Poly-Vinyl Chloride (PVC)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 103.33

Description

General part information

14UL1015 Series

14 AWG Hook-Up Wire 41/30 Black 600V 250.0' (76.2m)
