8810-TO220

Obsolete

3M (TC)

THERM PAD W/ADH WHT

8810-TO220

Obsolete

3M (TC)

THERM PAD W/ADH WHT

Description Specifications Series Pricing CAD Documents

Description

General part information

8810 Series

Thermal Pad White Rectangular Adhesive - Both Sides

Technical Specifications

Parameters and characteristics for this part

Specification	8810-TO220

Adhesive	Adhesive - Both Sides
Backing	Polyester
Carrier	Polyester
Color	White
Material	Acrylic
Shape	Rectangular
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	72 °F
Thermal Conductivity	0.6 W/m-K
Thickness	0.0098 in
Type	Transfer Tape
Usage	TO-220

8810 Series

Part	Shelf Life Start	Storage/Refrigeration Temperature	Shelf Life	Material	Outline Length	Outline Width	Carrier	Backing	Type	Adhesive	Color	Thickness	Thermal Conductivity	Shape	Usage	Outline Diameter
3M (TC) 8810-4-5	Date of Manufacture	72 °F	24 Months	Acrylic	4.57 m	101.6 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 9" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	228.6 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 8810-TO220	Date of Manufacture	72 °F	24 Months	Acrylic			Polyester	Polyester	Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular	TO-220
3M (TC) 8810-0.375-36	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	9.53 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 2.75" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	69.85 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 CIRCLE-1"-100	Date of Manufacture	72 °F	24 Months	Acrylic			Polyester	Polyester	Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Round		25.4 mm
3M (TC) 3M 8810 0.688" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	17.48 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 2.25" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	57.15 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 0.47" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	11.94 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular
3M (TC) 3M 8810 8" X 36YD	Date of Manufacture	72 °F	24 Months	Acrylic	32.92 m	203.2 mm	Polyester	Polyester	Roll Transfer Tape	Adhesive - Both Sides	White	0.0098 in	0.6 W/m-K	Rectangular

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Thermally Conductive Selection Guide

8810-TO220 | Datasheet
