74VCX16245LBR
ActiveSTMicroelectronics
IC TXRX NON-INVERT 3.6V 54TFBGA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
74VCX16245LBR
ActiveSTMicroelectronics
IC TXRX NON-INVERT 3.6V 54TFBGA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 74VCX16245LBR | 74VCX16245 Series |
|---|---|---|
| Current - Output High, Low | 24 mA | 24 mA |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Bits per Element | 8 | 8 |
| Number of Elements | 2 | 2 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Output Type | 3-State | 3-State |
| Package / Case | 54-TFBGA | 54-TFBGA, 48-TFSOP |
| Package / Case | - | 0.24 in |
| Package / Case | - | 6.1 mm |
| Supplier Device Package | 54-TFBGA (8x5.5) | 54-TFBGA (8x5.5), 48-TSSOP |
| Voltage - Supply [Max] | 3.6 V | 3.6 V |
| Voltage - Supply [Min] | 1.8 V | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
74VCX16245 Series
IC TXRX NON-INVERT 3.6V 54TFBGA
| Part | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Number of Elements | Current - Output High, Low | Package / Case | Output Type | Mounting Type | Voltage - Supply [Max] | Voltage - Supply [Min] | Number of Bits per Element | Package / Case | Package / Case [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
STMicroelectronics 74VCX16245LBR | 54-TFBGA (8x5.5) | 125 °C | -55 °C | 2 | 24 mA | 54-TFBGA | 3-State | Surface Mount | 3.6 V | 1.8 V | 8 | ||
STMicroelectronics 74VCX16245TTR | 48-TSSOP | 125 °C | -55 °C | 2 | 24 mA | 48-TFSOP | 3-State | Surface Mount | 3.6 V | 1.8 V | 8 | 0.24 in | 6.1 mm |
Description
General part information
74VCX16245 Series
Transceiver, Non-Inverting 2 Element 8 Bit per Element 3-State Output 54-TFBGA (8x5.5)
