QTH-060-02-L-D-A

Active

Samtec Inc.

CONN HDR 120POS SMD GOLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet QSH Series Other Related Documents 03 +2

QTH-060-02-L-D-A

Active

Samtec Inc.

CONN HDR 120POS SMD GOLD

Deep-Dive with AI

DocumentsDatasheet QSH Series Other Related Documents 03 +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	QTH-060-02-L-D-A

Connector Type	Header, Outer Shroud Contacts
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Height Above Board	7.26 mm
Height Above Board	0.286 "
Mated Stacking Heights	8 mm
Mounting Type	Surface Mount
Number of Positions	120
Number of Rows	2
Pitch [x]	0.5 mm
Pitch [x]	0.02 in

QTH-060 Series

...

Part	Number of Rows	Mated Stacking Heights	Number of Positions	Height Above Board	Height Above Board	Contact Finish	Connector Type	Pitch [x]	Pitch [x]	Features	Mounting Type	Contact Finish Thickness	Contact Finish Thickness	Height Above Board [z]	Height Above Board [z]
Samtec Inc. QTH-060-03-F-D	2	11 mm	120	10.27 mm	0.404 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Ground Bus (Plane)	Surface Mount	3 Áin	0.076 Ám
Samtec Inc. QTH-060-01-L-D-A-L-K	2	5 mm	120	4.06 mm	0.16 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Board Guide Ground Bus (Plane) Latches Pick and Place	Surface Mount	10 Áin	0.25 Ám
Samtec Inc. QTH-060-01-H-D-A-TR	2	5 mm	120	4.06 mm	0.16 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in		Surface Mount	30 Áin	0.76 Ám
Samtec Inc. QTH-060-04-L-D-LC	2	16 mm	120	15.24 mm	0.6 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Board Lock Ground Bus (Plane)	Surface Mount	10 Áin	0.25 Ám
Samtec Inc. QTH-060-01-L-D-A-GP-K	2	5 mm	120	4.06 mm	0.16 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Board Guide Ground Bus (Plane) Mating Guide Pick and Place	Surface Mount	10 Áin	0.25 Ám
Samtec Inc. QTH-060-08-L-D-DP-A	2	30 mm	120			Gold	Differential Pair Array Male	0.5 mm	0.02 in		Surface Mount	10 Áin	0.25 Ám	1.151 in	29.24 mm
Samtec Inc. QTH-060-02-L-D-A	2	8 mm	120	7.26 mm	0.286 "	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in		Surface Mount	10 Áin	0.25 Ám
Samtec Inc. QTH-060-01-F-D	2	5 mm	120	4.06 mm	0.16 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Ground Bus (Plane)	Surface Mount	3 Áin	0.076 Ám
Samtec Inc. QTH-060-01-L-D-A-GP	2	5 mm	120	4.06 mm	0.16 in	Gold	Header Outer Shroud Contacts	0.5 mm	0.02 in	Board Guide Ground Bus (Plane) Mating Guide	Surface Mount	10 Áin	0.25 Ám
Samtec Inc. QTH-060-10-L-D-DP-A	2	15 mm	120	14.27 mm	0.562 in	Gold	Differential Pair Array Male	0.5 mm	0.02 in		Surface Mount	10 Áin	0.25 Ám
