ERZ-V14 Series

Part	Current - Surge	Package Name	Package Diameter	Maximum DC Voltage	Varistor Voltage (Min)	Capacitance	Maximum AC Volts	Varistor Voltage (Max)	Mounting Type	Energy	Number of Circuits	Operating Temperature (Max)	Operating Temperature (Min)	Varistor Voltage (Typ)
Panasonic Electronic Components ERZ-V14D270	2 kA	Disc	15.5 mm	22 V	24 V	16000 pF	17 V	30 V	Through Hole	7.8 J	1	85 °C	-40 °C	27 V
Panasonic Electronic Components ERZ-V14D361CS	6000 A	Disc	14 mm	300 V	324 V	540 pF	230 V	396 V	Through Hole	130 J	1	85 °C	-40 °C	360 V
Panasonic Electronic Components ERZ-V14V820CS	6000 A	Disc	14 mm	65 V	73.8 V		50 V	90.2 V	Through Hole	20 J	1			82 V
Panasonic Electronic Components ERZ-V14D241	6000 A	Disc	15.5 mm	200 V	216 V	700 pF	150 V	264 V	Through Hole	84 J	1	85 °C	-40 °C	240 V
Panasonic Electronic Components ERZ-V14D271CS	6000 A	Disc	14 mm	225 V	247 V	640 pF	175 V	303 V	Through Hole	99 J	1	85 °C	-40 °C	270 V
Panasonic Electronic Components ERZ-V14D681	5 kA	Disc	16 mm	560 V	612 V	320 pF	420 V	748 V	Through Hole	190 J	1	85 °C	-40 °C	680 V
Panasonic Electronic Components ERZ-V14D680	2 kA	Disc	16 mm	56 V	61 V	5500 pF	40 V	75 V	Through Hole	20 J	1	85 °C	-40 °C	68 V
Panasonic Electronic Components ERZ-V14D220	2 kA	Disc	15.5 mm	18 V	20 V	20000 pF	14 V	24 V	Through Hole	6.3 J	1	85 °C	-40 °C	22 V
Panasonic Electronic Components ERZ-V14D621	5 kA	Disc	16 mm	505 V	558 V	330 pF	385 V	682 V	Through Hole	190 J	1	85 °C	-40 °C	620 V
Panasonic Electronic Components ERZ-V14D101CS	6000 A	Disc	14 mm	85 V	90 V	3200 pF	60 V	110 V	Through Hole	35 J	1	85 °C	-40 °C	100 V
