Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 71M6541F-DB | 71M6541 Series |
|---|---|---|
| Embedded | False | False |
| Function | Energy/Power Meter | Energy/Power Meter |
| Measurement Error | - | 0.1 % |
| Meter Type | - | Single Phase |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 64-LQFP |
| Supplied Contents | Cable(s), Power Supply, Board(s) | Cable(s), Power Supply, Board(s) |
| Supplier Device Package | - | 64-LQFP (10x10) |
| Type | Power Management | Power Management |
| Utilized IC / Part | 71M6541 | 71M6541 |
| Voltage - I/O High | - | 2 V |
| Voltage - I/O Low | - | 0.8 V |
| Voltage - Supply | - | 3 V |
| Voltage - Supply | - | 3.6 V |
