BLM9D0910-05AMZ

Active

Ampleon USA Inc.

BLM9D0910-05AM/LGA7X7/REELDP

Search across all available documentation for this part.

Active

Ampleon USA Inc.

BLM9D0910-05AM/LGA7X7/REELDP

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF Amplifier IC 859MHz ~ 960MHz 20-LGA (7x7)

Technical documentation and resources

Specification	BLM9D0910-05AMZ	BLM9 Series

	-	-
Frequency [Max]	960 MHz	1 - 960 GHz
Frequency [Min]	859 MHz	1.8 - 859 GHz
Gain	18 dBi	17.8 - 35.5 dB
Mounting Type	Surface Mount	Surface Mount
Package / Case	20-VLGA Exposed Pad	20-VLGA Exposed Pad, 20-QFN Exposed Pad, OMP-780-16F-1, OMP-780-16G-1
Supplier Device Package	20-LGA (7x7)	20-LGA (7x7), 20-PQFN (8x8), OMP-780-16F-1, OMP-780-16G-1
Voltage - Supply	-	28 - 48 V

Part	Mounting Type	Supplier Device Package	Gain	Package / Case	Frequency [Min]	Frequency [Max]	Voltage - Supply
Ampleon USA Inc. BLM9D2324-08AMZ	Surface Mount	20-LGA (7x7)	27 dB	20-VLGA Exposed Pad
Ampleon USA Inc. BLM9D3538-12AMZ	Surface Mount	20-LGA (7x7)	32 dB	20-VLGA Exposed Pad	3.4 GHz	3.8 GHz
Ampleon USA Inc. BLM9D2325-20ABZ	Surface Mount	20-PQFN (8x8)		20-QFN Exposed Pad	2.3 GHz	2.5 GHz	28 V
Ampleon USA Inc. BLM9D3740-16AMZ	Surface Mount	20-LGA (7x7)	31.2 dB	20-VLGA Exposed Pad	3.7 GHz	4 GHz	28 V
Ampleon USA Inc. BLM9D2327S-50PB		OMP-780-16F-1	27.5 dB	OMP-780-16F-1	2.3 GHz	2.7 GHz	28 V
Ampleon USA Inc. BLM9D2327S-50PBG	Surface Mount	OMP-780-16G-1	27.5 dB	OMP-780-16G-1	2.3 GHz	2.7 GHz	28 V
Ampleon USA Inc. BLM9D1822S-60PBGY	Surface Mount	OMP-780-16G-1	28.7 dB	OMP-780-16G-1	1.8 GHz	2.2 GHz	28 V
Ampleon USA Inc. BLM9D0910-05AMZ	Surface Mount	20-LGA (7x7)	18 dBi	20-VLGA Exposed Pad	859 MHz	960 MHz
Ampleon USA Inc. BLM9D1822-30BZ	Surface Mount	20-PQFN (8x8)	29.3 dB	20-QFN Exposed Pad	1.8 GHz	2.2 GHz	28 V
Ampleon USA Inc. BLM9D3438-16AMZ	Surface Mount	20-LGA (7x7)	32.5 dB	20-VLGA Exposed Pad	3.4 GHz	3.8 GHz	28 V
