ALPHA16/1M/SMAM/S/RP/17

Active

Siretta Ltd

RF ANT 2.4GHZ BLADE RP-SMA MALE

Search across all available documentation for this part.

Active

Siretta Ltd

RF ANT 2.4GHZ BLADE RP-SMA MALE

Technical Specifications

Parameters and characteristics commom to parts in this series

RF ANT 2.4GHZ BLADE RP-SMA MALE

Part	Gain	Applications	Height (Max) [Max]	Height (Max) [Max]	RF Family/Standard	Mounting Type	Antenna Type	VSWR	Termination	Frequency Range [Max]	Frequency Range [Min]	Number of Bands	Features	Features
Siretta Ltd ALPHA16/1M/SMAM/S/RP/17	2 dBic	Bluetooth, WLAN, Zigbee™	2 mm	0.079 in	802.15.4, Bluetooth, WiFi	Adhesive	Blade	2	RP-SMA Male	2.5 GHz	2.4 GHz	1
Siretta Ltd ALPHA16/3M/SMAM/RP/RA/17	2 dBic					Adhesive	Blade	2	RP-SMA Male	2.5 GHz	2.4 GHz	1	Cable	3 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA Bluetooth, WLAN, Zigbee™ Blade RP-SMA Male Adhesive
