400UDP1L1BLKM7RE

Active

E-Switch

SWITCH ROCKER DPDT 0.4VA 20V

Search across all available documentation for this part.

Active

E-Switch

SWITCH ROCKER DPDT 0.4VA 20V

Technical Specifications

Parameters and characteristics for this part

Specification	400UDP1L1BLKM7RE

Actuator Marking	No Marking
Actuator Type	Paddle
Circuit	DPDT
Color - Actuator/Cap	Black
Current Rating (Amps)	0.4 VA
Electrical Life	50000 Cycles
Features	Epoxy Sealed Terminals
Mounting Type	Through Hole, Vertical, Right Angle
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-30 ░C
Switch Function	On-On
Termination Style	PC Pin
Voltage Rating - AC	20 V
Voltage Rating - DC	20 V

Part	Actuator Type	Voltage Rating - DC	Termination Style	Voltage Rating - AC	Switch Function	Mounting Type	Electrical Life	Current Rating (Amps)	Color - Actuator/Cap	Operating Temperature [Min]	Operating Temperature [Max]	Features	Actuator Marking	Circuit
E-Switch 400UDP1L1BLKM7RE	Paddle	20 V	PC Pin	20 V	On-On	Right Angle Through Hole Vertical	50000 Cycles	0.4 VA	Black	-30 ░C	85 °C	Epoxy Sealed Terminals	No Marking	DPDT
E-Switch 400UDP1R1BLKM2RE	Concave (Curved)	20 V	PC Pin	20 V	On-On	Through Hole	50000 Cycles	0.4 VA	Black	-30 ░C	85 °C	Epoxy Sealed Terminals	No Marking	DPDT

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	504	$ 2.65

General part information

Rocker Switch DPDT 0.4VA (AC/DC) 20 V Through Hole, Right Angle, Vertical

Technical documentation and resources

No documents available
