MAXREFDES77#
ActiveAnalog Devices Inc./Maxim Integrated
DUAL-CHANNEL, HIGH-PRECISION, HI
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MAXREFDES77# |
|---|---|
| -3db Bandwidth | 80 kHz |
| Amplifier Type | Current Sense |
| Board Type | Fully Populated |
| Channels per IC | 2 - Dual |
| Current - Supply (Main IC) | 1.3 mA |
| Output Type | Single-Ended |
| Supplied Contents | Board(s) |
| Utilized IC / Part | MAX44285 |
| Voltage - Supply, Single/Dual (±) [Max] | 5.5 V |
| Voltage - Supply, Single/Dual (±) [Min] | 2.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAXREFDES77 Series
DUAL-CHANNEL, HIGH-PRECISION, HI
| Part | Amplifier Type | Current - Supply (Main IC) | -3db Bandwidth | Supplied Contents | Output Type | Utilized IC / Part | Voltage - Supply, Single/Dual (±) [Max] | Voltage - Supply, Single/Dual (±) [Min] | Channels per IC | Board Type |
|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXREFDES77# | Current Sense | 1.3 mA | 80 kHz | Board(s) | Single-Ended | MAX44285 | 5.5 V | 2.7 V | 2 - Dual | Fully Populated |
Description
General part information
MAXREFDES77 Series
MAX44285 2 - Dual Channels per IC Current Sense Amplifier Evaluation Board
