T 3276 550

Active

Amphenol Tuchel Industrial

CONN RCP HSG ML 3P PNL MT SNAPIN

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN RCP HSG ML 3P PNL MT SNAPIN

Technical Specifications

Parameters and characteristics for this part

Specification	T 3276 550

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Size	1.5 mm
Contact Type	Crimp
Fastening Type	Bayonet Lock
Housing Color	Black
Ingress Protection	IP40
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Snap-In
Note	Contacts Not Included
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Shell Material	Plastic
Shell Size - Insert	M16-3
Shielding	Unshielded
Type	For Male Pins

Part	Shell Size - Insert	Fastening Type	Contact Size	Ingress Protection	Insert Material	Mounting Type	Material Flammability Rating	Shielding	Contact Shape	Note	Housing Color	Contact Type	Connector Type	Shell Material	Orientation	Type	Operating Temperature [Max]	Operating Temperature [Min]
Amphenol Tuchel Industrial T 3276 550	M16-3	Bayonet Lock	1.5 mm	IP40	Thermoplastic	Panel Mount Snap-In	UL94 V-0	Unshielded	Circular	Contacts Not Included	Black	Crimp	Receptacle Housing	Plastic	Keyed	For Male Pins	100 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 3.23

General part information

3 Position Circular Connector Receptacle Housing Panel Mount, Snap-In
