MAX98389EWE+T
ActiveAnalog Devices Inc./Maxim Integrated
DIGITAL INPUT SLIM CLASS-D AMPLI
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX98389EWE+T
ActiveAnalog Devices Inc./Maxim Integrated
DIGITAL INPUT SLIM CLASS-D AMPLI
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX98389EWE+T | MAX98389 Series |
|---|---|---|
| Board Type | - | Fully Populated |
| Max Output Power x Channels @ Load | 1 channel, 1 channel | 1 channel |
| Max Output Power x Channels @ Load | 3.87 W, 8.02 W | 1 - 9.1 W |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Type | 1-Channel (Mono) | 1-Channel (Mono) |
| Package / Case | 16-WFBGA, WLBGA | 16-WFBGA, WLBGA |
| Supplied Contents | - | Board(s) |
| Supplier Device Package | 16-WLP (1.64x1.79) | 16-WLP (1.64x1.79) |
| Type | Class D | Class D |
| Utilized IC / Part | - | MAX98389 |
| Voltage - Supply [Max] | 10 V, 5.5 V | 5.5 - 10 V |
| Voltage - Supply [Min] | 3 V, 5 V | 2.3 - 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.52 | |
| 10 | $ 2.30 | |||
| 25 | $ 1.99 | |||
| 100 | $ 1.63 | |||
| 250 | $ 1.46 | |||
| 500 | $ 1.35 | |||
| 1000 | $ 1.26 | |||
| Digi-Reel® | 1 | $ 3.52 | ||
| 10 | $ 2.30 | |||
| 25 | $ 1.99 | |||
| 100 | $ 1.63 | |||
| 250 | $ 1.46 | |||
| 500 | $ 1.35 | |||
| 1000 | $ 1.26 | |||
| Tape & Reel (TR) | 2500 | $ 1.17 | ||
| 5000 | $ 1.11 | |||
| 7500 | $ 1.08 | |||
MAX98389 Series
DIGITAL INPUT SLIM CLASS-D AMPLI
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Type | Mounting Type | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Package / Case | Max Output Power x Channels @ Load | Max Output Power x Channels @ Load | Board Type | Utilized IC / Part | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX98389EWE+T | 3 V, 5 V | 5.5 V, 10 V | Class D | Surface Mount | 16-WLP (1.64x1.79) | 85 °C | -40 °C | 1-Channel (Mono) | 16-WFBGA, WLBGA | 1 channel, 1 channel | 3.87 W, 8.02 W | |||
Analog Devices Inc./Maxim Integrated MAX98389EVSYS# | 2.3 V | 10 V | 1-Channel (Mono) | 1, 9.1 W | Fully Populated | MAX98389 | Board(s) |
Description
General part information
MAX98389 Series
Amplifier IC 1-Channel (Mono) Class D 16-WLP (1.64x1.79)
