AMEPR30N-4250Z
Activeaimtec
LED DRIVER CC AC/DC 24-42V 500MA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMEPR30N-4250Z
Activeaimtec
LED DRIVER CC AC/DC 24-42V 500MA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMEPR30N-4250Z |
|---|---|
| Approval Agency | CE |
| Current - Output (Max) [Max] | 500 mA |
| Efficiency | 79 % |
| Features | OTP, SCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -30 ░C |
| Power (Watts) | 21 W |
| Ratings | IP62 |
| Size / Dimension [x] | 47 mm |
| Size / Dimension [x] | 1.85 in |
| Size / Dimension [y] | 6.61 in |
| Size / Dimension [y] | 168 mm |
| Size / Dimension [z] | 0.98 in |
| Size / Dimension [z] | 25 mm |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 305 V |
| Voltage - Input (Min) [Min] | 90 V |
| Voltage - Isolation | 3750 V |
| Voltage - Output [Max] | 42 V |
| Voltage - Output [Min] | 24 V |
| Weight | 180 g |
| Weight | 0.397 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 32.84 | |
| 5 | $ 29.43 | |||
| 10 | $ 28.69 | |||
| 15 | $ 28.40 | |||
| 25 | $ 27.83 | |||
| 50 | $ 27.28 | |||
| 75 | $ 26.05 | |||
| 100 | $ 23.00 | |||
| 200 | $ 22.31 | |||
Description
General part information
AMEPR30 Series
500mA 24 ~ 42V Constant Current LED Driver AC DC Converter Topology 1 Output
