52PL4DB

Active

Siemens

PILOT LIGHT,WHT,FV,INC,24 V

Search across all available documentation for this part.

Active

Siemens

PILOT LIGHT,WHT,FV,INC,24 V

Technical Specifications

Parameters and characteristics for this part

...

Part	Ingress Protection	Ratings	Type	Panel Cutout Shape	Lens Size [diameter]	Voltage	Lamp Color	Termination Style	Lens Color	Lens Transparency	Voltage [Max]	Voltage [Min]
Siemens 52PL4K2XY	IP20 IP66	AC	LED	Round	30 mm	600 V	Red	Screw Terminal
Siemens 52PL4L5	12 13 3 3R 4 4X NEMA 1	AC/DC	LED	Round		24 V			Blue
Siemens 52PL4XA	12 13 3 3R 4 4X NEMA 1		LED		30 mm
Siemens 52PL4DN	12 13 3 3R 4 4X NEMA 1	AC/DC	Incandescent		30 mm	24 V
Siemens 52PL4X3	12 13 3 3R 4 4X NEMA 1		LED		30 mm
Siemens 52PL4J3	IP20 IP66	AC	Incandescent	Round	30 mm	480 V	Clear	Screw Terminal		Clear
Siemens 52PL4DB	IP20 IP66	AC/DC	Incandescent	Round	30 mm	24 V	Clear	Screw Terminal		Clear
Siemens 52PL4RA			LED
Siemens 52PL4B9XB	IP20 IP66	AC/DC	LED	Round	30 mm	6 V	Yellow	Screw Terminal
Siemens 52PL4EX	12 13 3 3R 4 4X NEMA 1	AC/DC	LED		30 mm						240 V	6 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Incandescent Panel Indicator Clear Clear 24V Screw Terminal

Technical documentation and resources
