1871058-2
ActiveTE Connectivity AMP Connectors
PCI EXPRESS CONN. EON TYPE, 64P, L=2.0
1871058-2
ActiveTE Connectivity AMP Connectors
PCI EXPRESS CONN. EON TYPE, 64P, L=2.0
Description
General part information
1871058 Series
Board-to-Board, 64 Position, 1 mm [.039 in] Centerline, Vertical, Black, 11 mm [.433 in] Height, 8.88 mm [.35 in] Width, PCI & PCI Express Connectors
Technical Specifications
Parameters and characteristics for this part
| Specification | 1871058-2 |
|---|---|
| Card Thickness | 0.062 in |
| Card Type | PCI Express™ |
| Color | Black |
| Contact Finish | Gold-Palladium |
| Contact Finish Thickness | 30 µin |
| Contact Material | Copper Alloy |
| Features | Locking Ramp, Board Guide |
| Gender | Female |
| Material - Insulation | Thermoplastic |
| Mounting Type | Through Hole |
| Number of Positions | 64 |
| Number of Rows | 2 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.039 in |
| Read Out | Dual |
| Termination | Press-Fit |
