796137-2

Obsolete

TE Connectivity AMP Connectors

CONN HEADER R/A 1POS

Search across all available documentation for this part.

Obsolete

TE Connectivity AMP Connectors

CONN HEADER R/A 1POS

Technical Specifications

Parameters and characteristics for this part

Specification	796137-2

Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	1.27 µm
Contact Finish Thickness - Mating	50 µin
Insulation Color	Black
Insulation Height	0.425 in
Insulation Height	10.8 mm
Mounting Type	Through Hole, Right Angle
Number of Positions	1
Number of Positions Loaded	All
Number of Rows	1
Termination	Press-Fit

CONN HEADER R/A 1POS

Part	Insulation Height	Insulation Height	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Termination	Number of Positions Loaded	Number of Positions	Insulation Color	Mounting Type	Number of Rows
TE Connectivity AMP Connectors 796137-2	0.425 in	10.8 mm	1.27 µm	50 µin	Gold	Press-Fit	All	1	Black	Through Hole, Right Angle	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Connector Header Through Hole, Right Angle 1 position

Technical documentation and resources

No documents available
