H8PPS-1606G

Active

Assmann WSW Components

DIP CABLE - HDP16S/AE16G/HDP16S

Search across all available documentation for this part.

Active

Assmann WSW Components

DIP CABLE - HDP16S/AE16G/HDP16S

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

16 Position Cable Assembly Rectangular DIP to DIP, Reversed 0.500' (152.40mm, 6.00")

Technical documentation and resources

Parameters and characteristics commom to parts in this series

DIP CABLE - HDP16S/AE16M/HDP16S

Part	Pitch - Cable	Pitch - Cable	Usage	Cable Termination	Length [x]	Length [x]	Color	Number of Rows	Shielding	Contact Finish	Number of Positions	Connector Type	Pitch - Connector	Pitch - Connector	Length	Length	Length
Assmann WSW Components H8PPS-1618M	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC	457.2 mm	1.5 ft	Multiple, Ribbon	2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm
Assmann WSW Components H8PPS-1618G	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC	457.2 mm	1.5 ft		2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm
Assmann WSW Components H8PPS-1606G	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC				2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '
Assmann WSW Components H8PPS-1636M	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC	914.4 mm	3 ft	Multiple, Ribbon	2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm
Assmann WSW Components H8PPS-1636G	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC	914.4 mm	3 ft		2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm
Assmann WSW Components H8PPS-1606M	0.05 "	1.27 mm	Board In, Socket (0.3")	IDC			Multiple, Ribbon	2	Unshielded	Tin	16	DIP to DIP, Reversed	0.1 in	2.54 mm	152.4 mm	6 "	0.5 '
