Specification	EHRHT-2-I-F-6

Accuracy	2 %
Humidity Range (Maximum)	100 % RH
Humidity Range (Minimum)	0 % RH
Mounting Type	Chassis Mount
Operating Temperature (Max)	60 °C
Operating Temperature (Min)	-40 °C
Output Current (Max)	20 mA
Output Current (Min)	4 mA
Output Type	Analog Current
Package / Case	Module
Sensor Type	Temperature, Humidity
Voltage - Supply (Maximum)	36 VDC
Voltage - Supply (Minimum)	12 VDC

EHRHT Series

Part	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Mounting Type	Humidity Range (Maximum)	Humidity Range (Minimum)	Output Type	Sensor Type	Accuracy	Output Current (Max)	Output Current (Min)	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case
McGill Microwave Systems EHRHT-2-I-B-3	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	38 °C	-18 °C	Module
McGill Microwave Systems EHRHT-2-I-F-3	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	38 °C	-18 °C	Module
McGill Microwave Systems EHRHT-2-I-B-3	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	38 °C	-18 °C	Module
McGill Microwave Systems EHRHT-2-I-F-6	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	60 °C	-40 °C	Module
McGill Microwave Systems EHRHT-2-I-F-2	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	66 °C	-18 °C	Module
McGill Microwave Systems EHRHT-2-I-B-6	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	60 °C	-40 °C	Module
McGill Microwave Systems EHRHT-2-I-B-4	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	56 °C	0 °C	Module
McGill Microwave Systems EHRHT-2-I-B-5	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	54 °C	10 °C	Module
McGill Microwave Systems EHRHT-2-I-B-6	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	60 °C	-40 °C	Module
McGill Microwave Systems EHRHT-2-I-B-4	12 VDC	36 VDC	Chassis Mount	100 % RH	0 % RH	Analog Current	Humidity Temperature	2 %	20 mA	4 mA	56 °C	0 °C	Module
