PW1L-RYAFB002D0S

Active

IDEC Corporation

22MM PIEZO THIN RING 12VDC RED ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

PW1L-RYAFB002D0S

Active

IDEC Corporation

22MM PIEZO THIN RING 12VDC RED ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 79.26
		10	$ 68.35
		25	$ 64.42
		50	$ 61.60
		100	$ 58.89
Newark	Each	1	$ 87.31
		5	$ 83.07
		10	$ 80.95
		25	$ 72.05
		50	$ 66.12
		100	$ 62.30
		250	$ 60.18

Description

General part information

PW1L Series

Pushbutton Switch SPST-NO Piezo Panel Mount, Front

Documents

Technical documentation and resources

Datasheet

Specification	PW1L-RYAFB002D0S	PW1L Series

Actuator Marking	No Marking	No Marking
Actuator Type	Flush, Button, Round	Flush, Button, Round
Circuit	SPST-NO	SPST-NO
Color - Actuator/Cap	Silver	Silver
Electrical Life	50000000 Cycles	50000000 Cycles
Illumination Type, Color	Red, LED	Red, LED, Blue, White, Green, Green/Red, Yellow
Illumination Voltage (Nominal)	12 VDC	12 - 24 VDC
Ingress Protection	IP68, IP69K	IP68, IP69K
Mounting Type	Panel Mount, Front	Panel Mount, Front
Operating Temperature [Max]	75 ░C	75 ░C
Operating Temperature [Min]	-40 °C	-40 °C
Panel Cutout Dimensions [diameter]	22.2 mm	22.2 mm
Switch Function	Off-Mom	Off-Mom
Termination Style	Wire Leads	Wire Leads
Type	Piezo	Piezo
Voltage Rating - AC	24 V	24 V
Voltage Rating - DC	24 V	24 V

Part	Illumination Voltage (Nominal)	Switch Function	Termination Style	Ingress Protection	Voltage Rating - AC	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Color - Actuator/Cap	Panel Cutout Dimensions [diameter]	Voltage Rating - DC	Actuator Type	Electrical Life	Illumination Type, Color	Actuator Marking	Type	Circuit
IDEC Corporation PW1L-RYAFB002D0S	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	LED, Red	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-RYAFB002D0B	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	Blue, LED	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-RYAFB002D0W	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	LED, White	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-RYAFB002E0S	24 V	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	LED, Red	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-R6AFB002P0G	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	Green, LED	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-RYAFB002D2A	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	Green/Red, LED	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-R6AFB002J0G	24 V	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	Green, LED	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-R6AFB002J0S	24 V	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	LED, Red	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-R6AFB002PSG	12 VDC	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	Green/Red, LED	No Marking	Piezo	SPST-NO
IDEC Corporation PW1L-RYAFB002E0Y	24 V	Off-Mom	Wire Leads	IP68, IP69K	24 V	-40 °C	75 ░C	Panel Mount, Front	Silver	22.2 mm	24 V	Button, Flush, Round	50000000 Cycles	LED, Yellow	No Marking	Piezo	SPST-NO

Part

Illumination Voltage (Nominal)

Switch Function

Termination Style

Ingress Protection

Voltage Rating - AC

Operating Temperature [Min]

Operating Temperature [Max]

Mounting Type

Color - Actuator/Cap

Panel Cutout Dimensions [diameter]

Voltage Rating - DC

Actuator Type

Electrical Life

Illumination Type, Color

Actuator Marking

Type

Circuit

IDEC Corporation

PW1L-RYAFB002D0S

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

LED, Red

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-RYAFB002D0B

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

Blue, LED

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-RYAFB002D0W

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

LED, White

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-RYAFB002E0S

24 V

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

LED, Red

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-R6AFB002P0G

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

Green, LED

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-RYAFB002D2A

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

Green/Red, LED

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-R6AFB002J0G

24 V

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

Green, LED

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-R6AFB002J0S

24 V

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

LED, Red

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-R6AFB002PSG

12 VDC

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

Green/Red, LED

No Marking

Piezo

SPST-NO

IDEC Corporation

PW1L-RYAFB002E0Y

24 V

Off-Mom

Wire Leads

IP68, IP69K

24 V

-40 °C

75 ░C

Panel Mount, Front

Silver

22.2 mm

24 V

Button, Flush, Round

50000000 Cycles

LED, Yellow

No Marking

Piezo

SPST-NO
